XCMG 53M Truck Mounted Concrete Construction Equipment With SINOTRUK Chassis

XCMG 53M Truck Mounted Concrete Construction Equipment With SINOTRUK Chassis

  • XCMG 53M Truck Mounted Concrete Construction Equipment With SINOTRUK Chassis
  • XCMG 53M Truck Mounted Concrete Construction Equipment With SINOTRUK Chassis
  • XCMG 53M Truck Mounted Concrete Construction Equipment With SINOTRUK Chassis
XCMG 53M Truck Mounted Concrete Construction Equipment With SINOTRUK Chassis
Product Details:
Place of Origin: CHINA
Brand Name: XCMG
Certification: CCC
Model Number: HB37
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: Negotiable
Packaging Details: Nude.
Delivery Time: 30-40 Days After Pay Deposit.
Payment Terms: LC/TT
Supply Ability: 5000UNITS/MONTH
Contact Now
Detailed Product Description
Brand:: XCMG Dimension(L*W*H):: 12310*2500*3990mm
Weight:: 49750kg Max. Grade-ability:: 20%
Theoretical Throughput :: 120/170 M³/h Color:: White/Red/Yellow/Blue
High Light:

truck mounted concrete pump

,

mobile cement mixer trucks

XCMG 53M Truck Mounted Concrete Pump Construction Equipment With SINOTRUK Chassis



One Button Stabilization Technology:

The one button stabilization technology quickly dampens any boom movement resulting from repositioning the boom. This allows precise positioning of the end hose.

Boom Anti Vibration Technology:

The boom anti vibration technology reduces vibration during pumping by 50% allowing less movement and greater control of the end hose.

Energy Saving Technology:

With cycle times of up to 29 per minute (at 12MPa), pump efficiency is increased up to 25% while fuel consumption is decreased by up to 10%.

Anti Overswing Technology:

By adopting our new swing brake technology, the boom's overswing amplitude is reduced by 60%

Fault Self Diagnostic Technology:

Continually monitors more than 200 aspects of the system during operation. Faults are displayed on the monitor. Review of the detected faults can reduce troubleshooting time by 70%.

Smart Boom System:

One Button Boom Extend/Retract

Press upward on the boom extend/retract button to extend the boom or press downward to retract the boom automatically.

Coordinated Section Operation

The boom can be rapidly and accurately repositioned by coordinating the movement the first and second sections

Safety Technology:

Boom Overload Protection Technology

Relief valves are mounted on the boom cylinder counterbalance valves. These valves will release pressure in the event of excessive boom load to prevent damage to the boom.

Hopper Screen Interlock Technology

As an operator protection measure, the pump will automatically stop when the hopper screen is opened.

Hydraulic Oil Level Monitoring

The oil level in the hydraulic reservoir is continually monitored. If the level drops below a preset level, an alarm will sound and the pump will be stopped to prevent damage to the hydraulic system.



Main Parameters:



Item Parameter
Outline dimensions (Length´ Width ´Height)mm 12310×2500×3990
Fuel type Diesel
Engine emission standard Euro III
Displacement/Powerml/kW 12100/279
Steering type Steering wheel
No. of axle 4
Wheel basemm 1793+4407+1370
No. of spring leaf (front/rear) 2+3/9
Tire 12.00R20
Track (front/rear)mm 2034/1831
No. of tire (exclude spare tire) 12
Total vehicle weightkg 36500
Crew in cab 2
Approach angle/Departure angle 21°/12°
Front overhang /Rear overhangmm 1360/3380
Max. speedkm/h 94
Min. ground clearancemm 270
Max. grade-ability 38%
Fuel consumption per 100kmL/100km 40
Chassis Model FM12
Grade
Manufacturer VOL VO
Engine Model D12
Manufacturer VOL VO



Theoretical throughput m³/h 120/170
Pumping concrete pressure MPa 12/8
Number of theoretical pumping /min 18/27
Transport cylinder inner diameter*stroke mm Φ260*2200
Feeding height mm 1480
Structure type   7RZ
Placing boom max height/depth/radius m 53/37.3/48.3
Turning angle of the boom . ±270



FAQ:



Q1.How about the delivery time?

A1:Usually it takes about 7-30 days to produce.



Q2.What about the guarantee?

A2:1 year and we can offer you some spare parts for free for first order.



Q3.What should I do for the quality problems?

A3:If you meet quality problems please send to me the products photo fitst,our after service department will deal with for you.



Q4.Did you have a good orgonization of shipping vessle ?

A4:Yes,we work with many famous ship company like PIL,COSCO,CMA,MCS,MAERSK etc for many years and they offer us very good price.



Q5. What's the payment method?

A5: 30% T/T as Deposit, Balance 70% TT before shipping.



Q6. How about shipment?

A6: 20FT container, 40FT container,40FT high container,opentop container,flat bed container ,RoRo ship or bulk ship according to the size of the products
