| Place of Origin: | CHINA |
| Brand Name: | SINOTRUK |
| Certification: | CC |
| Model Number: | ZZ5707S3640AJ |
| Minimum Order Quantity: | 1 UNIT |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Nude |
| Delivery Time: | 30-45 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 500 UNITS/Month |
| Cab:: | HW7D | Gear Box:: | Manual 10 Speeds |
|---|---|---|---|
| Tire:: | 14.00R25 | Model:: | ZZ5707S3640AJ |
| Overall Dimension(mm): | 8450×3300×4100 | Color:: | Optional |
| High Light: | diesel dump truck,sinotruk howo dump truck |
||
Description:
HOWO brand water Truck is produced by SINOTRUK.Adopt WD615 series of 6-cylinder in line, 4-stroke, water cooled, turbo-charged inter-cooled,direct injection engine.Have good power economy.
And the brake system have huge advantages.Service brake:dual circuit compressed air brake
Parking brake (emergency brake):spring energy,compressed air operating on rear wheels
Auxiliary brake:engine exhaust valve brake., and it can achieve continuously variable transmission.Rich experience and well after-sale service.
(1) The overseas engineers are always ready to deal with unexpected needs.
(2) More than 40 years' experience as a manufacturer, more than 12 years exporting experience.
(3) Products Quality Certification SGS CCC ISO
(4) Export to more than 30 countries and regions
(5) Regularly callback to know the vehicle's working status.
Packing:
Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
1. Question: What's your payment term?
Answer: We accept T/T(30% down payment and balance before shipping) and L/C mostly. But if you prefer other payment terms please contact us for further information.
2. Question: How about the delivery time?
Answer: Fot the HOWO mining dump truck for coal we will ship it in 40 days after down payment.
3. Whats's the warranty time?
Answer: We provide one year warranty for the mining dump truck.
4. How do you offer the after sale service?
Answer: We offer after sale service life long. Engineers are available to go abroad for training and spare parts will be sent at the soonest.
| HOWO MINING TIPPER TRUCK MAIN SPECIFICATION | |||
| Model | ZZ5707S3640AJ | Steering | ZF8098 |
| Engine | Brand SINOTRUK | Loading Weight | 50000kg |
| WD615.47 Euro II | Tyres | 14.00R25(36 level) Radial tyre | |
| Maximum Output | 371HP | Cab | Left hand driving |
| Rated engine power (KW/r/min) | 273/2200 | No sleeper | |
| Air-condition | |||
| Transmission | HW19710 (10forward,2reverse) | Max Speed | 50 km/h |
| Front Axle | HF12 | ||
| Max loading : 12000kg | Body | Floor 12mm | |
| Rear Axle | AC26 Ratio: 10.47 | Side 8mm | |
| Max loading : 26000kg | Hydraulic Cylinder | Front Tipper | |
| Overall Dimension(mm) | 8450×3300×4100 | ||
| Electrics |
Operating voltage:24V,negative grounded Starter:24V,7.5 Kw Alternator:3-phase,28V,1500 W Batteries:2x12 V,165 Ah horn,headlamps,fog lights,brake lights,indicators and reverse light |
||
