RP403 75KW 12840kg Mini Road Concrete Pavers / Asphalt Paving Machine

RP403 75KW 12840kg Mini Road Concrete Pavers / Asphalt Paving Machine

  • RP403 75KW 12840kg Mini Road Concrete Pavers / Asphalt Paving Machine
  • RP403 75KW 12840kg Mini Road Concrete Pavers / Asphalt Paving Machine
  • RP403 75KW 12840kg Mini Road Concrete Pavers / Asphalt Paving Machine
RP403 75KW 12840kg Mini Road Concrete Pavers / Asphalt Paving Machine
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: XCMG
Certification: CE/ISO9001
Model Number: RP403
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Nude
Delivery Time: 10-30 days
Payment Terms: L/C, T/T
Supply Ability: 1000 sets/month
Contact Now
Detailed Product Description
Model Number: RP403 Weight: 11500kg
Rated Power: 118kW Paving Width: 4.5m
Dimension(L*W*H): 5500*1800*3629mm Warranty: 1 Year
Condition: New
High Light:

asphalt sprayer equipment

,

asphalt distributor truck

XCMG Official Manufacturer RP403 75KW 12840kg xcmg mini road concrete pavers asphalt paver machine asphalt paver price



Product Quick Details:



Warranty:1 year

Condition:New

Paving Width:1800~4200 mm, 1800~4200mm

Place of Origin:Jiangsu, China (Mainland)

Brand Name:XCMG

Dimension(L*W*H):5500mm 1800mm 3580mm

Weight:11.5 t

Certification:ISO

engine:DEUTZ

Rated Power:75KW

Transport Weight:11.5 t

Product name:Mini Road Concrete Pavers Machine

Name:Pavers Machine

Feature:Pavers Machine

Max Paving Thickness:200mm

Max Paving Speed:30m/min

Max Travel Speed:3.6km/h

After-sales Service Provided:Engineers available to service machinery overseas



Product Features:



Miniaturization of the machine, 1.8 meters ultra-small machine width, optional width limiting device, minimum paving width of 0.8 meters, suitable for paving maintenance of milling "grooves", using hydraulically independent drive, crawler walking The device is equipped with a water-cooled turbocharged diesel engine (75kW/2000rpm), a powerful three-phase alternator with generator management system, and the generator adopts independent drive technology. The hydraulic system adopts load-sensitive control technology on both sides. The hoppers can be individually folded and oscillating follow-up inference. The electronic control system design is a CAN bus technology platform, a network control system of the CPU control technology, and an automatic leveling device.

Product Specification:

Specification Unit RP403
dimension mm 5535*1800*3580
Weight t 9.5
Driving speed km/h 3.6
Basic pave width m 1.8-3.4
Maximum pave width m 4.2
Maximum layer thickness mm 200
Maximum paving speed m/min 30
Hopper capacity t 12
Maximum laydown rate t/h 300
Rate power kw/rpm 75/2200
