20 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers

20 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers

  • 20 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers
  • 20 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers
  • 20 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers
20 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers
Product Details:
Place of Origin: Jiangsu, China
Brand Name: XCMG
Certification: CE ISO
Model Number: XP203
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: nude
Delivery Time: 45days
Payment Terms: T/T, L/C
Contact Now
Detailed Product Description
Power(W): 86KW Travel Speed: 4-18.4KW/H
Weight: 20ton UNIQUE SELLING POINT: Fully Hydraulic System
Warranty: 1 Year Engine Brand:: CHANGCHAI
High Light:

road work equipment

,

road construction vehicles



20 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers XCMG


Quick Details



Power(W):86KW

Travel Speed:4-18.4KW/H

After-sales Service Provided:Free spare parts, Video technical support, Online support

Warranty:1 Year

Condition:New

Type:light vibratory rollers

Grade Ability:20%

Place of Origin:Jiangsu, China

Brand Name:XP203

Dimension(L*W*H):2500*1200*1750mm

Weight:20ton

Certification:CE ISO

Product name:20 Ton earth compactor machine road roller XP203

Engine Model:SC4H115.4G2B

Tire size:11.00-20-16pr

Rated Power(kW):26kw

Ground pressure:200-400kpa

Compacting width:2250mm

Total length:4800mm

Total width:2356mm

Total height:3330mm

Fuel consumption:≤205(1±5%)



Product Description



XP203
1. Engine: YC4A125Z
2. Roated Power: 92kw
3. Amount: front 4, rear 5



XP163/XP203 tyre compactor is the landmark of 3 series products developed on the basis of 2 series products. It leads the development of Chinese tyre compactor due to its high start, high technique, high performance, and high quality. The machine features beautiful appearance, driving comfort, simple operation, excellent performance, safety and reliability, and convenient maintenance. It can be applied in the construction of asphalt road, base layer, hypo-base layer, and fill construction. It is a necessary compact equipment for road construction and water conservancy construction, especially for the high-grade highways.

Driving comfort
Spacious and bright cab features wide view and comfort. Both-side operation can absolutely avoid rolling the curb and the compacting blind corners.

Simple operation
There are two steering wheels, two seats, and two independent control systems for operations. The speed change adopts electric control handle and two-speed gear shift design, which can respectively meet the requirements of compaction and site transfer, together with flexible electronic control operation and comfortable handfeel, greatly reduces the labor intensity of the drivers.

Excellent performance
Adopting the pneumatic tyre to compact the layer will not damage the compacted materials. The compact performance can be improved by adding or reducing the counterweight and changing the inflation pressure of the tyres. Because of the kneading effect produced by the tyre's elasticity, the material displacement will be produced in all directions, forming even dense surface without cracks, which can prolong the service life of the road.

Adopt the front wheels swing mechanism. When the machine works on rough road, the mechanism ensures the even ground pressure, which can make the materials be compacted evenly.

The optional international leading infrared tyre heating system realizes the no water sprinkling work of the compactor, and improves the density and service life of the road.



Specifications

Model Unit XP203
Min. working weight kg 11740
Max. working weight kg 20000
Ground pressure kPa
Travel speed km/h 200-400
Speed I 4.2
Speed II 8.2
Speed III 17.4
Reverse speed I 4.17
Reverse speed II 8.2
Theoretical gradeability % 20
Min. turning external radius mm 7330
Min. ground clearance mm 250
Compaction width mm 2250
Roller overlap amount mm 45
Tyre specification   11.00-20-16PR
Amount   FrontFront 4 Rear rear 5
Engine model   YC4A125Z
Type   Water cooling, pressurizing
Rated power kw @2200 r/min 92
Engine oil consumption g.kw/h ≤230
Hydraulic oil tank capacity L 60
Diesel oil tank capacity L 150
Overall length mm 4770
Overall width mm 2250
Overall height mm 3285



Product pictures



20 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers 020 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers 120 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers 220 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers 320 Ton Earth Compactor Machine Road Roller XP203 Light Vibratory Rollers 4
