| Place of Origin: | CHINA |
| Brand Name: | BEIBEN |
| Certification: | CCC/CE/ISO9001 |
| Model Number: | NG80B 2631K |
| Minimum Order Quantity: | 1 UNIT |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Package in Nude |
| Delivery Time: | 30-45 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 UNITS/Month |
| Model:: | NG80B | Driving Type:: | 6x4 |
|---|---|---|---|
| Engine Power:: | 310hp | Engine Model:: | Weichai Brand |
| Wheel Base (mm): | 3800+1450 | Overall Dimension:: | 8530X2500X3430 |
| Tire: | 12.00R20 | Color:: | Orange/Red/White |
| Highlight: | sand dump truck,construction dump truck |
||
Beiben 2534K 380HP 6x4 10 wheeler Dumper Truck Short Cab LHD
Company Profile:
Beginning in 1989, CNGC Inner Mongolia First Machinery Group started imported from Germany NG80 heavy-duty tucks 20 models of foundation design, include: drawings, manufacturing process, technical standards and production equipment, At the end of 1989, the first China assembled Mercedes heavy trucks had finished from production line, It fills the blank that china could not produce high-grade heavy trucks, it lays the foundation of Beiben Company¡¯s future.
At the moment, BeiBen Heavy-Duty Company has established 3 producion bases which is in BaoTou, ChongQing and PengLai.
Main Specs:
1. Engine:Wei chai engine
2. Loading Weight: 40000kg to 60000KG
3. Superiority: Leader in heavy duty truck industry
4, left hand drive or right hand drive
Why choose beiben 6x4 truck head ?
1. Good performance, durable and elastic
2. The lowest price with top quality in China
3. Standard materials according to technical drawing
4. OEM service, quality assurance
5. Professional supplier with many years experience
SPECIFICATION(ND3254B38)
| Wheel base (mm) | 3800+1450 | |||
| Overall Dimension: | 8530X2500X3430 | |||
| Curb weight (kg) | 12300 | |||
| Front overhang/rear overhang (mm) | 1410/1870 | |||
| Approach angle/Departure angle | 26/33 | |||
| Max speed(km/h) | 85 | |||
|
Engine
|
Model | WP10.380E32,water-cooled,four strokes,6 cylinders straight in line,turbocharged, | ||
| Fuel type | Diesel | |||
| Min rate of consuming fuel(g/(kw.h)) |
198g/kw.h |
|||
|
Rated Power / rotating (kw/(r/min) |
279Kw/2200rpm 380HP |
|||
| Emission | EURO III EGR | |||
| Maximum Torque / rotating speed(n.m/(r/min) | 1350Nm/1100-1600rpm | |||
| Displacement(ml) | 9726 | |||
| Fuel tanker capacity (L) | 400L Iron | |||
| Clutch | Model | #430, Single dry frictional disc,Hydraulic boosting | ||
| Gearbox | Model |
9JS150A mechanical type,mechanical type,Based on Fuller Eaton technology , 9 Forward speed gear. |
||
| Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system | ||
| Assistant brake | Engine exhaust brake | |||
| Park brake | Potential springs pressing on middle and rear wheels | |||
| Steering system | Model | ZJ120D, whole circulation in ball type, hydraulic boosting | ||
|
Suspension System
|
Front Suspension,
|
Non-free standing leaf spring,telescopic shock absorber with stabilizer bar suspension,10pcs spring | ||
|
Rear Suspension
|
Non-free standing stabilization spring, stabilization suspension,13pcs. | |||
| Frame |
Same width, same sections Based on Germany Benz Technology |
|||
| Front axle (Mercedes Benz Technology) |
Double-shoe pneumatic brake, 7.5t no-driving steering axle |
|||
| Middle and Rear axle (Mercedes Benz Technology) |
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, 13 tons double reduction driving axle, speed ratio 5.921 Middle axle: HD7/016DGS-13/5.263
Rear axle: HL7/015DS-13/5.263
|
|||
| Tire | 12.00R20 radial tire | |||
| Qty of tire | 11 (10+1) | |||
|
Electrical system
|
Battery | 2X12V/135Ah | ||
| Generator | 28V-70A | |||
| Starter | 5.4Kw/24V | |||
|
Cab
|
NG80B Left hand drive Short cab without sleeper Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly; |
|||
|
Interior trimming: : Integral interior trimming, Integral instrument, digital instrument, radio (with USB interface+MP3), high back/shock absorption seat for driver, high back seat for co-driver. Steering wheel can be adjusted. With inner A/C. |
||||
|
Exterior trimming: Metal bumper, two steps, new mirror. |
||||
The specification and the picture just for reference, Final confirmed by us.
Products Photos:
Our Services
Presale Serivce:
Professional sales team supply personalized service according to customer's requirement.
Order operation:
We will start production of your order within 3 days with strict quality control.
Shipping:
According to different shipping requirements,our company logistics department will ship the Beiben tractor truck to you with our professional service. The necessary custom clearance documents such as contract, commercial invoice, packing list, certificate of origin will be sent to you.
After-sales Service:
Regularly callback to know the Beiben tractor truck working status and offer reasonable tech proposals.
Timely spare parts supply to guarantee the truck working continuously.
Our oversea engineers are ready all the time to serve.
Contact Person: Mr. Zhang
Tel: 86-15275410816
