1.0 M3 Concrete Construction Equipment With Yuchai Engine And 5.2 Tons Weight

1.0 M3 Concrete Construction Equipment With Yuchai Engine And 5.2 Tons Weight

    • 1.0 M3 Concrete Construction Equipment With Yuchai Engine And 5.2 Tons Weight
    • 1.0 M3 Concrete Construction Equipment With Yuchai Engine And 5.2 Tons Weight
    • 1.0 M3 Concrete Construction Equipment With Yuchai Engine And 5.2 Tons Weight
    • 1.0 M3 Concrete Construction Equipment With Yuchai Engine And 5.2 Tons Weight
  • 1.0 M3 Concrete Construction Equipment With Yuchai Engine And 5.2 Tons Weight

    Product Details:

    Place of Origin: CHINA
    Brand Name: FK
    Certification: ISO/CCC
    Model Number: FK

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 UNIT
    Price: Negotiable
    Packaging Details: Nude
    Delivery Time: 30-45 work days
    Payment Terms: L/C, T/T
    Supply Ability: 500 units/month
    Contact Now
    Detailed Product Description
    Dimension(L*W*H):: 5100*2650*2700mm Power(W):: 78kw
    Emission Standard:: Euro II Driving Type:: 4*4
    Engine Model:: Yuchai Weight:: 5200 KG
    High Light:

    truck mounted concrete pump

    ,

    mobile cement mixer trucks

    Euro II 4X4 1.0 M3 Concrete Construction Equipment With Yuchai Engine And 5.2Tons Weight



    Description:


    Concrete Mixer is the preferred machinery for rural road construction, cement floor, floor, pile watering concrete, aqueduct repair, River Dam and other projects.

    Concrete Mixer adopts 78KW engine, full hydraulic 265 torque converter, wheel side hydraulic steering drive bridge, and equipped with driving image; The car has hydraulic electronic scale weight can accurately weigh gravel, cement, and can automatically quantify the water, so that the concrete ratio is more accurate.

    Concrete mixer combines the functions of the existing concrete transporter and the mixing station, and sets the loader, mixer and transporter in one, which can automatically feed, stir and unload the material, and realize the integration of transportation and site construction work. Greatly improve the efficiency and equipment utilization rate, reduce labor costs!



    Packing:



    Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.The main machine nude, attached parts and tools put into standard export box.Within 20 days deliver the goods to main Port.Ro-Ro ship or bulk ship or according to customer requiring.We have professional forwarding partners.


    Competitive Advantage:



    1) Automatic weighing ,to ensure the quality of mixing.

    2) Quantitative addition of water to make more uniform mixing,more in line with standards.

    3) Increased water tank effectively saves water time and improves work efficiency.

    4)Panoramic cab,wide field of vision ,space to increase,no dead ends ergonomic design.

    5)Pilot operation is flexible and convenient.



    Parameter

    Mobile

    MT-1.0

    Net

    6600kg



    Transmission

    Hydraulic

    4X4

    Brake

    Pneumatic brake



    Wheelbase

    Front and rear independent system

    2200mm

    Loader capacity

    500L

    Loader control

    Hydraulic

    Tilt angle

    30°



    Speed

    High 0-10km/h

    Low 0-30km/h

    Tire

    20.5/70-16

    Voltage DC

    24V DC

    Hydraulic tank

    140L

    Diesel tank

    100L

    Dimensions(L*W*H)

    6860*2420*4120mm

    Loader control

    Hydraulic pilot control handle

    Diesel engine

    Type

    YUCHAI YCD4J22G

    Rated power/rpm

    78KW/2200rpm

    Cylinder

    4-cylinder

    Starter

    Electric

    Mixing drum

    Drum capacity

    1.2cbm,4.8-6.0cbm/hr

    Angle of drum rotation

    270°

    Discharge height

    1.7m

    Chute

    Swing angle

    120°

    Angle control

    Hydraulic

    Water tank

    Supply

    Hydraulic water pump

    Water tank

    2*250L





    1.0 M3 Concrete Construction Equipment With Yuchai Engine And 5.2 Tons Weight 01.0 M3 Concrete Construction Equipment With Yuchai Engine And 5.2 Tons Weight 1
