XCMG ZL50GN Wheel Loader with 162kW Engine 3.0m³ Bucket Capacity and ABS Anti-lock Braking System

XCMG ZL50GN Wheel Loader with 162kW Engine 3.0m³ Bucket Capacity and ABS Anti-lock Braking System

  • XCMG ZL50GN Wheel Loader with 162kW Engine 3.0m³ Bucket Capacity and ABS Anti-lock Braking System
  • XCMG ZL50GN Wheel Loader with 162kW Engine 3.0m³ Bucket Capacity and ABS Anti-lock Braking System
  • XCMG ZL50GN Wheel Loader with 162kW Engine 3.0m³ Bucket Capacity and ABS Anti-lock Braking System
  • XCMG ZL50GN Wheel Loader with 162kW Engine 3.0m³ Bucket Capacity and ABS Anti-lock Braking System
XCMG ZL50GN Wheel Loader with 162kW Engine 3.0m³ Bucket Capacity and ABS Anti-lock Braking System
Product Details:
Place of Origin: China
Brand Name: XCMG
Certification: iso/ccc
Model Number: XCMG LOADER
Payment & Shipping Terms:
Minimum Order Quantity: 1 PCS
Price: Negotiation
Packaging Details: Nude
Delivery Time: 30-45 work days
Payment Terms: L/C,T/T
Supply Ability: 500 units/month
Contact Now
Detailed Product Description
Product Loader: XCMG LOADER Certification: TUV, ISO, RoHS, CE
Tread: 3300mm Grade: Light Duty
Tire Number: 4 Self-dumping: Not Self-dumping
ABS Anti-lock Braking System: ABS Anti-lock Braking System Transmission: Hydraulic
Bucket Capacity: 2.5~4.5m3 Machine Weight: 17500kg
Highlight:

Used Mini Wheel Front Loader

,

Mini Wheel Front Loader

,

Heavy Duty Wheel Front Loader

Used New OEM Construction Tractor Hydraulic Heavy Duty 4WD Mini Wheel Front Loader
XCM G ZL50GN Wheel Loader
The XCM G ZL50GN is a globally recognized heavy-duty construction machine, designed for exceptional performance and reliability in demanding industrial applications.
Key Features
  • Powerful Engine: Equipped with 162kW Weichai WD10G220E23 engine for robust performance
  • Impressive Traction & Capacity: 160kN traction force with 3.0m³ bucket capacity
  • Weight & Lifting: 17.5-18.0 tons operating weight, 5000kg maximum lifting capacity
  • Dump Height: 3200mm maximum dump clearance
  • Enhanced Stability: Extended wheelbase and optimized structure for complex terrains
  • Operator Comfort: Ergonomic cab with noise reduction technology
Ideal for construction sites, mining operations, and other demanding environments, the XCM G ZL50GN combines power, stability, and comfort to deliver outstanding performance.
Technical Specifications
Description Unit LW300FN LW300KN
Rated operating load kg 3000 3000
Bucket capacity m³ 1.5-2.5 1.5-2.5
Machine weight kg 10600±200 10900±200
Dump clearance at maximum lift mm 2770~3260 2770~3260
Reach at maximum lift mm 3110~3710 1010~1210
Wheel base mm 2600 2900
Tread mm 1850 1850
Height of hinge at maximum lift height mm 3830 3830
Working height (fully lifted) mm 4870 4870
Max. breakout force kN 130 130
Max. horse power kN 95 95
Hydraulic cycle time - raise s 5.5 5.4
Total hydraulic cycle time s 10 9.3
Min. turning radius over tyres mm 5165 5170
Articulation angle ° 35±1 38±1
Gradeability ° 28 28
Tyre size 17.5-25-12PR 17.5-25-12PR
Overall machine dimension L×W×H mm 7050*2482*3118 7245*2482*3320
Model WP6G125E22 WP6G125E201
Emission standards Emission 2 Emission 2
Rated Power/Speed kW/rpm 92/2200 92/2000
Fuel Tank L 170 170
Hydraulic Tank L 170 175
1-gear (F/R) km/h 8/10 12/16
2-gear (F/R) km/h 13/30 38
XCMG ZL50GN Wheel Loader with 162kW Engine 3.0m³ Bucket Capacity and ABS Anti-lock Braking System 0 XCMG ZL50GN Wheel Loader with 162kW Engine 3.0m³ Bucket Capacity and ABS Anti-lock Braking System 1
Contact Us: For more details or to explore customization options, feel free to contact our technical team.
