HOWO 8x4 Dump Truck: A Reliable Choice for Heavy-Duty Transport

Key Specifications

• Chassis Model: ZZ3317N3567C1
• Driving Type: 8x4
• Production Year: 2024 (new model)
• Engine:
  • Make: SINOTRUK
  • Model: WD615.47, Euro 2, 371 HP / WP12.400E201, Euro 2, 400 HP
  • Type: 6-cylinder in-line, water-cooled, turbocharged and intercooled
  • Displacement: 9.726 L
• Transmission: HW19710, 10F & 2R, with PTO
• Steering: ZF power steering, model ZF8118, hydraulic steering with power assistance
• Front Axle: HF9, 2×9000 KGS, double T-cross section beam
• Rear Axle: HC16, 2×16000 KGS, pressed axle housing, central single reduction with hub reduction and differential locks
• Ratio: 5.73
• Propeller Shaft: Double universal joint propeller shaft with gear-shaped coupling flange
• Chassis:
  • Frame: U-profile parallel ladder frame with section of 300x80x8mm, reinforced sub-frame with cold-riveted cross members
  • Front Suspension: 10 semi-elliptic leaf springs, hydraulic telescopic double-action shock absorbers, and stabilizer
  • Rear Suspension: 12 leaf semi-elliptic springs, bogie spring, and stabilizer
• Brake System:
  • Service Brake: Dual circuit compressed air brake
  • Parking Brake (Emergency Brake): Spring energy, compressed air operating on front shaft and rear wheels
  • Auxiliary Brake: Engine exhaust brake
• Electrics:
  • Operating Voltage: 24 V, negative grounded
  • Starter: 24 V, 5.4 Kw
  • Alternator: 3-phase, 28 V, 1500 W
  • Batteries: 2×12 V, 165 Ah
  • Additional Features: Cigar lighter, horn, headlamps, fog lights, brake lights, indicators, and reverse light
• Tires: 12.00R20, radial tires with one spare tire (optional: 315/80R22.5 tubeless tires)
• Fuel Tank: 300 L
• Cargo Body:
  • Dimensions: 7300×2300×1700 mm, 28.54 CBM
  • Floor Thickness: 8 mm, Side Thickness: 6 mm
  • Front Lifting System: Available

Features and Advantages

• Robust Design: Built with a strong and reliable chassis, ensuring durability in demanding environments.
• High Capacity: Large cargo body capacity makes it ideal for large-scale transport tasks.
• Ergonomic Cab: Features a comfortable HW76 cab with a built-in sleeper, air conditioning, and advanced controls for operator comfort.
• Advanced Safety: Integrated braking system and complete electrical configuration ensure driving safety and stability.
• Versatility: Adaptable to various engineering needs, making it popular in construction and mining industries.

Applications

• Construction: Transporting materials like sand, gravel, and debris.
• Mining: Hauling ores and heavy loads.
• Logistics: Efficient transportation for large-scale projects.
