Chinese Sinotruck Howo 400hp Tipper 8x4 Mini 60 Ton Canter new Dump Truck

Chinese Sinotruck Howo 400hp Tipper 8x4 Mini  60 Ton Canter new Dump Truck

Basic Specifications

• Model: HOWO 8×4 dump truck.
• Cab: Typically features the HW76 cab, which is spacious and comfortable, with an integrated sleeper for rest during long-distance transportation. Some models are equipped with a galvanized bumper that has good corrosion resistance and can effectively protect the front of the vehicle from collisions.

Chassis and Axles

• Chassis Frame: Utilizes a U-shaped parallel ladder frame with dimensions of 300x80x8mm, reinforced with cold-riveted cross members. This provides high strength and reliability, capable of withstanding significant loads and bumpy road conditions.
• Front and Rear Axles: The front axle is typically the VGD95 model with a load capacity of 2x9,000kg, featuring a double T-section beam for steering. The rear axle is the HC16 model with a load capacity of 2x16,000kg, using a pressed axle housing, central single reduction with hub reduction, and differential locks between wheels and axles.

Power System

• Engine: Equipped with SINOTRUK's efficient diesel engines, such as the WD615.47 engine with 371hp or the WP12.400 engine with 400hp. These engines feature six cylinders in-line, water cooling, turbocharging, and intercooling. They deliver strong power, reliable performance, and good fuel efficiency while meeting Euro II emission standards.
• Transmission: Generally uses the HW19710 transmission, offering 10 forward gears and 2 reverse gears. This provides a wide range of gear ratios to meet different driving conditions and hauling requirements. Some models also come with a power take-off (PTO) function.

Suspension and Braking System

• Suspension System: The front suspension consists of 10 semi-elliptical leaf springs, hydraulic telescopic double-acting shock absorbers, and stabilizers. The rear suspension uses 12 semi-elliptical leaf springs, bogie springs, and stabilizers. This configuration provides strong load capacity and good shock absorption, ensuring comfortable driving on bumpy roads.
• Braking System: Features a dual-circuit compressed air braking system for service brakes, with spring energy and compressed air operation on the front axle and rear wheels for parking (emergency) brakes. An auxiliary engine exhaust brake is also included. This ensures reliable braking performance and high safety during driving.

Cargo Box

Electrical System

Other Features

• Steering System: Equipped with ZF power steering, model ZF8118, featuring hydraulic steering with power assistance. This ensures light and flexible steering, reducing driver fatigue.
• Tires: Typically uses 12.00R20 radial tires, with some models offering optional 315/80R22.5 or 12R22.5 tires. These tires provide good grip and wear resistance, ensuring driving safety on various road conditions.
• Fuel Tank: Features a 300L fuel tank, meeting long-distance transportation needs and reducing refueling frequency.

  Basic information
  Announcement type:	ZZ3317V326GF1	Driving form:	8X4
  Wheelbase:	1950+3225+1350mm	Engine:	Weichai WP12.430E62
  Transmission:	12-speed transmission	Body length:	9.93 m
  Body width:	2.55m	Body height:	3.55m
  Front wheel base:	2022/2022mm	Rear wheel base:	1860/1860mm
  Vehicle weight:	15.5 tons	Rated load:	15.37 tons
  Total mass:	31 tons	Tonnage class:	Heavy truck
  Approach Angle:	17 degrees	Departure Angle:	21 degrees
  Engine parameter
  Engine type:	Weichai WP12.430E62	Engine brand:	Weichai
  Number of cylinders:	6	Type of fuel:	Diesel oil
  Displacement:	11.6 L	Emission standard:	Six kingdoms
  Maximum horsepower:	430hp	Maximum output power:	316kW
  Maximum torque:	2100 n. m	Maximum torque speed:	1000-1400rpm
  Rated speed:	1900rpm	Engine form:	CR+DOC+DPF+Hi_SCR
  Container parameter
  Length of container:	6.8 m	Width of container:	2.35m
  Container height:	1.5m	Container form:	Self-discharging type
  Transmission parameter
  Transmission model:	12-speed transmission	Forward gear:	12th gear
  Number of reversals:	2
  Chassis parameter
  Allowable load of front axle:	6500/7000kg	Rear axle allowable load:	17500(biaxial group)kg
  Number of spring pieces:	2007/7/10
  tyre
  Tire specifications:	12.00 R20	Number of tires:	12
