Dongfeng 6X4 18cbm Vacuum Sewage Suction Truck with 8m Sewage Suction Pipe and 6x4 Drive Wheel

Dongfeng 6X4 18cbm Vacuum Sewage Suction Truck with 8m Sewage Suction Pipe and 6x4 Drive Wheel

  • Dongfeng 6X4 18cbm Vacuum Sewage Suction Truck with 8m Sewage Suction Pipe and 6x4 Drive Wheel
  • Dongfeng 6X4 18cbm Vacuum Sewage Suction Truck with 8m Sewage Suction Pipe and 6x4 Drive Wheel
  • Dongfeng 6X4 18cbm Vacuum Sewage Suction Truck with 8m Sewage Suction Pipe and 6x4 Drive Wheel
  • Dongfeng 6X4 18cbm Vacuum Sewage Suction Truck with 8m Sewage Suction Pipe and 6x4 Drive Wheel
Dongfeng 6X4 18cbm Vacuum Sewage Suction Truck with 8m Sewage Suction Pipe and 6x4 Drive Wheel
Product Details:
Place of Origin: CHINA
Brand Name: HOWO
Certification: ISO
Model Number: HOWO
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiate
Packaging Details: nude
Delivery Time: 40 worker days
Payment Terms: L/C,T/T
Supply Ability: 300 units/mouth
Contact Now
Detailed Product Description
Product Name: 6*4 Sewage Suction Truck Tank Volume: 15000L-20000L
Drive Wheel: 6x4 Vacuum Pump: Chinese Brand, Italy Brand Or Other Imported Brand
Suction Time: <5min Sewage Suction Pipe: 8m
Effective Suction Range: >8m Gearbox: 8 Forwards & 1 Reverse
Highlight:

18cbm Vacuum Sewage Suction Tanker Truck

,

Dongfeng Vacuum Sewage Suction Tanker Truck

,

18tons Vacuum Sewage Suction Tanker Truck

Dongfeng 6X4 18cbm 18tons Vacuum Sewage Suction Tanker Truck
Professional vacuum sewage suction truck designed for efficient waste management and transportation applications.
Key Features & Configurations
  • Available chassis options: Dongfeng, FAW, Sinotruk Howo, ISUZU, FOTON, SHACMAN, JMC, JAC, CAMC
  • Drive type options: 4x2, 4x4, 6x4, 8x4 and more
  • Tanker capacity range: 2cbm to 25cbm
  • Comprehensive accessory package including PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system
Technical Specifications
Parameter Specification
Overall Size (mm) 9400×2500×3700
Sewage Tank Capacity 18 CBM
Gross Weight (kg) 25000
Curb Weight (kg) 12700
Approaching/Departure Angle (°) 23/13
Front/Rear Suspension (mm) 1250/2500
Maximum Speed (km/h) 90
Standard Configuration
  • 18m³ sewage suction tank constructed from 6mm carbon steel
  • Observation sewage window for monitoring
  • Self-flow exit and cleaning device
  • Oil water separator and overflow valve
  • Hydraulic lifting sewage tank mechanism
  • 8m sewage suction pipe
  • Vertical suction range: 9m
  • Pumping full tank time: 10 minutes
  • Discharging full tank time: 8 minutes
Chassis Parameters
Parameter Specification
Chassis Brand Dongfeng
Chassis Model EQ1258VFJ2
Drive Type 6×4, 3 axles
Transmission 10-speed manual
Cab One and a half cabin, 3 passengers
Tire Specification 10.00-20
Tire Quantity 10
Wheelbase (mm) 4350+1300
Leaf Spring Configuration 9/10, 9/13
Front Trend/Rear Trend (mm) 1960/1860
Axle Loading (kg) 6700/18000
Engine Parameters
Parameter Specification
Engine Brand Weichai
Engine Model C260 33
Engine Type Diesel, 6 cylinder, turbocharged, inter-cooled
Horse Power 260 hp
Displacement/Power 8300ml / 191kw
Emission Standard Euro 3
Dongfeng 6X4 18cbm Vacuum Sewage Suction Truck with 8m Sewage Suction Pipe and 6x4 Drive Wheel 0
