Dongfeng HOWO 4×2 Sewage Suction Truck with 12m3 Tank Capacity and 190HP Engine for Efficient Sludge Removal

Product Details:

Place of Origin:	CHINA
Brand Name:	DONGFENG
Certification:	ISO
Model Number:	DONGFENG

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	Negotiate
Packaging Details:	nude
Delivery Time:	40 worker days
Payment Terms:	L/C,T/T
Supply Ability:	300 units/mouth

Contact Now

Detailed Product Description

Product Name:	4*2 DONGFENG Sewage Suction Truck	Payload:	7.25t
Transmission Type:	Manual	Fuel:	Diesel
Tank Volume:	3940L	Hoesrpower:	108HP
Condition:	New	Front/Rear Overhang:	1175/2370
Highlight:	Dongfeng HOWO Sludge Suction Truck , High Capacity Sludge Suction Truck , Sewage Treatment Vehicle Sludge Suction Truck

Dongfeng HOWO High-Capacity Sludge Suction Truck & Sewage Treatment Vehicle

Dongfeng 4×2 Sewage Suction Truck Overview

The Dongfeng 4×2 sewage suction truck is a highly efficient and versatile vehicle engineered for the collection and transportation of sewage, sludge, and septic waste. Designed for optimal performance in demanding environments.

Basic Configuration

Chassis: Robust Dongfeng chassis built for durability and performance in challenging conditions
Drive Configuration: 4×2 drive system providing excellent maneuverability and control across various terrains
Tank Capacity: Available in 5,000 to 12,000 liter capacities to meet diverse operational requirements
Tank Material: Constructed with 5mm Q235B material for longevity and wear resistance; stainless steel options available

Engine and Pump System

Engine: Powerful engine options including 120-horsepower models for effective suction and transport operations
Vacuum Pump: High-capacity liquid-ring vacuum pump with 420 m³/h (120 L/s) flow rate and maximum pressure limit of -90,000 Pa

Operational Features

Steering Options: Available in both Left-Hand Drive (LHD) and Right-Hand Drive (RHD) configurations
Suction Performance: Up to 10 meters vertical suction height and 80 meters horizontal suction distance
Discharging Mechanism: Hydraulic lifting rear-open system for controlled and efficient discharge
Inhalable Diameter: DN100 diameter for efficient substance suction
Suction Pipe Diameter: DN102 pipe diameter for optimal substance intake

Key Advantages

High Efficiency: Powerful vacuum pump and hydraulic system enable rapid suction and transportation
Durability: Dongfeng chassis and high-quality materials ensure reliability and reduced maintenance
Versatility: Suitable for urban sanitation, industrial waste treatment, and sewage pipe cleaning applications
Excellent Mobility: 4×2 drive configuration provides superior adaptability across diverse road conditions

Technical Specifications

Vehicle Overview

Name	Sewage Suction Truck
Dimension (L×W×H)	9150×2550×3550 mm
Total Mass	18000 kg
Rated Payload	5270 kg
Curb Weight	12600 kg
Passenger Capacity	3
Approach/Departure Angle	17°/10°

Chassis Parameters

Model	DFH1180
Driving Type	4×2 Left/Right Hand Drive
Wheelbase	4500 mm
Gearbox	Nine Speed Forward, One Reverse Manual
Tire	10.00R20 18PR
Number of Tires	6+1 (Spare Tire)
Front/Rear Suspension	1400/3050

Engine Parameters

Manufacturer/Model	D6.7NS6B230
Rated Power	190Hp, 210Hp, 230Hp
Fuel Type	Diesel Oil
Displacement/Capacity	6700 ml
Emission Standard	Euro3
Cylinder Configuration	Straight/6/Intercooling

Equipment Parameters

Tank Capacity	12 m³
Vacuum Pump Rotation Speed	800-1400 r/m
Maximum Suction Lift	>7 m
Vacuum	>500 mmHg
Time for Full Suction	<5 min
Common Accessories	Vacuum pump, ball valve, oil cylinder for rear cap, oil cylinder for dumping, pressure meter, window for showing liquid level, lock system for rear cap, four-way valve, moisture separator, sprinkler (optional), alarm for full suction (optional)
