6*4 Drive Wheel 5000L Tank Volume Sewage Suction Truck with 251-350hp Horsepower

6*4 Drive Wheel 5000L Tank Volume Sewage Suction Truck with 251-350hp Horsepower

  • 6*4 Drive Wheel 5000L Tank Volume Sewage Suction Truck with 251-350hp Horsepower
  • 6*4 Drive Wheel 5000L Tank Volume Sewage Suction Truck with 251-350hp Horsepower
  • 6*4 Drive Wheel 5000L Tank Volume Sewage Suction Truck with 251-350hp Horsepower
  • 6*4 Drive Wheel 5000L Tank Volume Sewage Suction Truck with 251-350hp Horsepower
6*4 Drive Wheel 5000L Tank Volume Sewage Suction Truck with 251-350hp Horsepower
Product Details:
Place of Origin: CHINA
Brand Name: SHACMAN
Certification: ISO
Model Number: SHACMAN
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiate
Packaging Details: nude
Delivery Time: 40 worker days
Payment Terms: L/C,T/T
Supply Ability: 300 units/mouth
Contact Now
Detailed Product Description
Product Name: SHACMAN 6*4 5cbm Sewage Suction Vacuum Tank Truck Tank Volume: 5000L
Drive Wheel: 6*4 Hoesrpower: 251-350hp
Tank Material: Q235 Carbon Steel/Head 5.0mm, Q235 Carbon Steel/5. Front Axle: Hf9
Capacity: 12m3 Emission: Euro 2
Highlight:

16cbm Sewage Tanker Truck

,

16cbm Sewage Suction Truck

,

Shacman Sewage Suction Truck

16cbm Shacman Fecal Suction Vehicle Sewage Tanker Truck
This professional sewage suction truck is designed for efficient collection, transportation, and discharge of various liquids including dirty water, sludge, septic waste, crude oil, and solid materials such as small stones and bricks. Ideal for cleaning sewers, cesspits, and gullies, it serves critical roles in environmental sanitation and waste management operations.
Core Functions
Also known as truck-mounted sewage cleaner, vacuum cleaner truck, or waste vacuum truck, this vehicle handles multiple waste management applications with superior performance and reliability.
Key Equipment Features
  • Complete sewage suction system with PTO, transmission shaft, and vacuum suction sewage pump
  • High-pressure molding tank with moisture and gas-oil separation systems
  • Multiple directional control valves and comprehensive pipe network
  • Hydraulic cylinder tank lifting capability (40-45 degrees)
  • Hydraulically operated rear door for easy access
  • Available tank capacities from 3,000 to 25,000 liters
Performance Specifications
  • EU vacuum pump (Italian brand) or equivalent Chinese top-brand double vacuum pumps
  • Pump operation via hydraulic motor or auxiliary engine
  • Overfill protection system with audible alarm
  • Superior suction power with high efficiency
  • Durable construction for long service life
  • Suction time ≤ 5 minutes with effective range ≥ 8 meters
Technical Specifications
Vehicle Configuration
Parameter Specification
Driving Type 6x4, Single Row
Overall Dimensions (mm) 10500×2300×3500
Wheel Base (mm) 4600+1350
Wheel Track Front/Rear (mm) 1960/1860
Approach/Departure Angle (°) 28/32
Maximum Speed (km/h) 95
Weight Specifications
Weight Type Capacity (KGS)
Tare Weight 5340
Payload 6025
Front Axles Loading 2700
Rear Axles Loading 5000
Power System
Component Specification
Engine Brand Weichai
Horse Power 210 HP
Emission Standard Euro V
Gearbox 6 Forwards & 1 Reverse
Steering Left Hand Drive
Tire Specification 11.00R20, 6 tires with one spare
Sewage Tank System
Parameter Specification
Tank Volume 20,000 Liters
Tank Material 6mm Carbon Steel Q235
Tank Size 4900x1600mm
Vacuum Pump Chinese Vacuum Pump or Italy Vacuum Pump
Sewage Suction Pipe 8 Meters
Additional Equipment
Oil-gas separator, water-gas separator, four-way valve, anti-flow valve, washing device, pressure gauge, ball valve
Customization Available: Custom painting colors and logos can be applied according to customer requirements.
6*4 Drive Wheel 5000L Tank Volume Sewage Suction Truck with 251-350hp Horsepower 0
