(1)Vacuum sewage suction truck (also called truck mounted sewage cleaner, vacuum cleaner truck, vacuum suction truck, vacuum suction tanker, vacuum waste collection truck, sewage suction truck, sewage vacuum truck, waste vacuum truck, sewer truck, cesspit emptier, gully emptier, etc.) is used to collect, transport and discharge liquid such as dirty water, sludge, septic, crude oil and solid stuff such as small stones, bricks as well. It is suitable for cleaning the sewer, cesspit, gully, etc. It is widely used in environment and sanitation field.
(2)Accessory of sewage suction function: Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.
(3)vacuum tank capacity ranges from 3,000 Liters to 20,000 liters
Product Description
Features:
1.Cylinder vacuum tank can be lifted hydraulically to 40-45 degree.Rear door can be opened and closed hydraulically.
2.Adopt EU vacuum pump (Italy brand) or equivalent China top brand double vacuum pumps,super powerful,highly efficient.
3.Pump can be operated by a hydraulic motor or by an auxiliary engine.
4.Overfill system with music horn is equipped ,preventing the vacuum pump damage from sewage water into vacuum pump when the tank is full.
5.Nice shape ,rational structure,durable and long service life
| Chassis Specification |
| General |
Chassis Brand |
Shacman |
| Overall dimension |
9010*2480*3100mm |
| GVW |
25000kg |
| Mass in working order |
10500kg |
| Cab |
Cab Capacity |
2 persons allowed |
| Air Conditioner |
Heating or cooling air conditioner |
| Engine |
Fuel Type |
Diesel |
| Engine Brand |
WEICHAI |
| Power |
380HP |
| Displacement |
7520ml |
| Emission Standard |
Euro 3 |
| Chassis |
Drive Type |
6*4 (left hand driving) |
| Transmission |
Manual |
| Wheelbase |
4600+1300mm |
| Tire |
11.00R20 (10+1) |
| Max Speed |
90km/h |
| Electric system |
24v |
| Upper-Body Specification |
| Upper body |
Body capacity |
16-18cbm |
| Material |
Carbon Steel |
| Vacuum Pump Brand |
Italy BP/Weilong/Domestic |
| Vacuum Pump Advantage |
High efficient, |
| Vacuum rate 93%, |
| Quick suction and discharge |
| Hose |
Wire strengthened hose |
| Standard accessories |
Inlet pipeline,Discharge nozzle,Cabin pneumatic control box,basic tool kit |
| Optional |
Back alarm and Camera can be equipped. |
| Standard carbon steel,stainless steel optional. |
| Standard WEILONG vacuum pump,Italy vacuum pump. |
