Name: Hot Sale off-Road Wide-Body Dump Truck 60 Ton Tl875 Mining Truck
Brand: Shandong Global Heavy Truck Import&Export Co.,Ltd
SKU: howo
Price: 135,000.00 USD
Availability: InStock

Home Products Mining Dump Truck

Hot Sale off-Road Wide-Body Dump Truck 60 Ton Tl875 Mining Truck

Product Details:

Place of Origin:	China
Brand Name:	sinotruk
Certification:	iso/ccc
Model Number:	howo

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	Negotiation
Packaging Details:	Nude
Delivery Time:	30-45 work days
Payment Terms:	L/C,T/T
Supply Ability:	100Unit/Units per month

Contact Now

Detailed Product Description

Model NO.:	TL875	Power:	Diesel
Load Capacity:	60 Ton	Emission Standard:	Euro 3
Machine Weight:	90 Ton	Min. Turning Radius:	11 M
Transport Package:	Suitable Package For Shipment	Specification:	910534703975 Mm
Highlight:	Off Road Mining Dump Truck , Wide Body Mining Dump Truck , 60 Ton Mining Dump Truck

Hot Sale off-Road Wide-Body Dump Truck 60 Ton Tl875 Mining Truck Cheap Price

TL875 off-highway dump truck is the most popular series of 6*4 mining dump truck designed and manufactured by Tonly.
No.1 Market share of 6*4 Mining Dump Trucks in China and the possessing capacity is over 33,000 units in the world.

High Performance and Highlights
* The transport capacity TL875 series can reach to more than 60 tons.

* TL875 off-road dump truck is our most mature mining dump truck with the most stable performance in the industry.

* Under the same operation condition, the transport capacity of TL875 for one single trip can over 60 tons and the attendance rate is more than 85% with the high comprehensive efficiency.

* The intelligent control system of IBS auxiliary braking, the steering system of dual steering gear and the safety defense system are adopted to guarantee TL875 mining dump truck more safety under any operation conditions.

Model	TL875B	TL875D
Engine	Weichai 430Hp	Weichai 480Hp
Gearbox	Fast 7DS180	Fast 8DS240
Front Axle	20T	20T
Drive Axle	35T + 35T	35T + 35T
Lifting System	Single Cylinder Front Lifting	Single Cylinder Front Lifting
Tire	14.00-25	14.00-25
Standard Bucket Capacity (m³)	Heaped 30 Struck 35	Heaped 30 Struck 35
Drive Mode	6×4	6×4
Curb Mass (t)	30	30
Rated Loading Capacity (t)	60	60
Maximum Total Mass (t)	90	90
Overall Dimension (mm)	9105×3470×3975	9105×3470×3975
Maximum Speed (km/h)	40	45
Maximum Gradeability (%)	32	32
Minimum Turning Radius (m)	11	11
Minimum Ground Clearance (mm)	385	385
Approach Angle / Departure Angle (°)	24/47	24/47
Braking Distance	<15(V0=30km/h)	<15(V0=30km/h)
