Name: 6X4 380HP 400HP 10 Wheeler 40ton Sinotruk HOWO Tipper Dumper Dump Truck
Brand: Shandong Global Heavy Truck Import&Export Co.,Ltd
SKU: howo-7
Price: 37,000.00 USD
Availability: InStock

Home Products Heavy Duty Dump Truck

6X4 380HP 400HP 10 Wheeler 40ton Sinotruk HOWO Tipper Dumper Dump Truck

Product Details:

Place of Origin:	China
Brand Name:	sinotruk
Certification:	iso,
Model Number:	howo-7

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	NEGOTIABLE
Packaging Details:	nude
Delivery Time:	40 worker days
Payment Terms:	L/C,T/T
Supply Ability:	500 units/month

Contact Now

Detailed Product Description

Model NO.:	Howo 6*4 Dump Truck	Transmission Type:	Manual
Load Capacity:	31-40t	Drive Wheel:	6×4
Horsepower:	380hp	Tire Certification:	ECE, GCC, ISO, DOT
Condition:	New	Drive Seat:	Air Suspension Seat
Highlight:	HOWO Tipper Dumper Dump Truck , Tipper Dumper Dump Truck 6X4 , 40 Ton Tipper Dumper Dump Truck

6X4 380HP 400HP 10 Wheeler 40ton Sinotruk HOWO Tipper Dumper Dump Truck

Sinotruk 6×4 tipper trailer truck is a very common bulk cargo transport vehicle with a very wide range of applications and strong application capabilities.
This type of dump truck trailer is mainly composed of a vehicle chassis, an engine, a hydraulic lifting device, a cargo compartment, and a cab, and the cargo is unloaded by operating the hydraulic lifting system.
The dump truck has strong loading capacity, good toughness, no deformation and fracture, and can adapt to more complex road conditions, such as: mountain roads, highways, and dirt roads.
We have different types and configurations of heavy dump truck trailers for you to choose, and we also support customized production to help you better complete transportation business.

Truck Model	ZZ3257N3647
Truck Brand	SINOTRUK-HOWO
Driving Style	Left Hand Driving
Dimension(Lx W xH)(unloaded)	8214x2496x3170
Cargo body size (LWH, mm)	5600x2300x1500 19.32m3
Cargo thickness(mm)	Bottom:8mm, Side:6mm
Lift type of Carriag	Middle side
Approaching angle/Departure angle(°)	19/26
Overhang(front/rear) (mm)	1500/1739
Wheel base (mm)	3625+1350
Max speed(km/h)	75
Curb weight(kg)	12290
Loading Weight(kg)	30000
Fuel tanker capacity	300
Fuel consumption(L/km)	20-40 L/100 km
Clutch	Single-plate dry clutch Φ420mm

Fuel type	Diesel
Horse Power	336hp
Emission	EURO II
Engine Model (Steyr technology, made in China)	WD615.69,water-cooled,four strokes,6 cylinders in line with water cooling , directly injection
Transmission Model	HW15710,10 forwards and 2 reverse
Steering system Model	ZF8098 hydraulic steering with power assistance
Front axle	HF9,Steering with double T-cross section beam
Rear axle	HC16,casting axle housing,central double reduction with differential locks between axles and wheels
Color	Optional (White ,Red ,yellow )
Tyre	11.00-20,11 pieces
Battery	2X12V/165Ah
Alternator	28V-1500kw
Starter	7.5Kw/24V
Cab	HW76 cab, (one sleeper,with air-condition)
