Manual Transmission Sinotruk HOWO 380 HP 6X4 Tipper / Dumper / Dump Truck

Manual Transmission Sinotruk HOWO 380 HP 6X4 Tipper / Dumper / Dump Truck

  • Manual Transmission Sinotruk HOWO 380 HP 6X4 Tipper / Dumper / Dump Truck
  • Manual Transmission Sinotruk HOWO 380 HP 6X4 Tipper / Dumper / Dump Truck
  • Manual Transmission Sinotruk HOWO 380 HP 6X4 Tipper / Dumper / Dump Truck
  • Manual Transmission Sinotruk HOWO 380 HP 6X4 Tipper / Dumper / Dump Truck
Manual Transmission Sinotruk HOWO 380 HP 6X4 Tipper / Dumper / Dump Truck
Product Details:
Place of Origin: China
Brand Name: howo
Certification: iso,ce
Model Number: howo-7
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: NEGOTIABLE
Packaging Details: nude
Delivery Time: 40 worker days
Payment Terms: L/C,T/T
Supply Ability: 500 units/month
Contact Now
Detailed Product Description
Model NO.: Howo 6*4 Dump Truck Transmission Type: Manual
Load Capacity: 40t Drive Wheel: 6×4
Horsepower: 371hp Tire Certification: ECE, GCC, ISO, DOT
Condition: New Drive Seat: Air Suspension Seat
Highlight:

HOWO 6*4 Tipper Dump Truck

,

6X4 Tipper Dump Truck

,

380 HP Tipper Dump Truck

Hot sale Sinotruk HOWO 380 HP 6X4 Tipper/Dumper/Dump Truck for Prices

Product Description – HOWO-7 380HP Dump Truck

The HOWO-7 380HP dump truck is a powerful and reliable heavy-duty vehicle designed for efficient transportation of construction materials and mining loads. Built by SINOTRUK with advanced German MAN technology, this truck combines robust performance, durability, and low operating cost, making it an ideal choice for various harsh working environments.

Key Features:

  • Model: HOWO-7 6×4 Dump Truck

  • Engine: WP10.380E22, Euro II emission standard, 380 horsepower

  • Cab: HW76 new front face cab with single sleeper and A/C

  • Gearbox: HW19710 manual transmission, 10 forward & 2 reverse gears

  • Drive Axle: MCY16 double rear axle, final drive ratio 5.451

  • Front Axle: VGD95 axle

  • Steering System: BOSCH technology steering gear

  • Tires: 12.00R20 radial tires (18PR), suitable for mixed terrain

  • Fuel Tank: 300L capacity for extended operation

  • Dump Body Size: Customizable, typically 5600–5800mm length

  • Hydraulic System: Front hydraulic lifting system for fast unloading

  • Max Speed: Up to 75–82 km/h

  • Color: Optional standard colors available

Advantages:

  • High-powered engine for heavy load operations

  • Durable chassis and axles designed for long service life

  • Efficient fuel consumption and easy maintenance

  • Comfortable and safe driving experience

  • Ideal for construction, mining, and earthwork projects


SINOTRUK HOWO 6x4 DUMP TRUCK SPECIFICATIONS
Truck Model ZZ3257N3847B1(Left Hand Drive )
Truck Brand SINOTRUK-HOWO
Dimension (LxWxH) (unloaded)mm 8645×2550×3450
Body Carriage Internal Dimension:5600x2300x1500 mmSteel thickness of Carriage:Floor:8mm/Side:6mmHydraulic Lift of Carriage:Middle LiftSteel:Q235
Approaching angle/ Departure angel (°) 19/23
Overhang (front/rear) (mm) 1500/1870
Wheel base (mm) 3825+1350
Max. Driving speed (km/h) 75
Front axle loading capacity (kg) 9500
Rear axle loading capacity(kg) 2*16000
Curb weight (kg) 12750
Gross vehicle weight 30000
Cab Model SINOTRUK HW76 Lengthen cab,single bunk,all steel forward control, 55° hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds, laminate windscreen, with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, heating & ventilation system, adjustable roof flap, with stereo radio/MP3, sun visor, and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorber with transverse stabilizer, safety belt, air conditioner.
Engine Model Model WP10.340E22(EURO II),340hp,6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection
Rated Power(kw/rpm) 249/2200
Make WEICHAI, Euro II emission standard, Thermostat with 80ºC opening begin, Rigid fan
Clutch SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance
Transmission Model SINOTRUK HW19710 transmission ,10 forward and 2 reverse
Brake system  Service brake Dual circuit compressed air brake
Parking Brake(emergency brake) Spring energy, compressed
Steering system Model Gear Box ,hydraulic steering with power assistance.(Left hand driving)
Front axle SINOTRUK VGD95 Front Axle,new 9.5-ton front axles of equipped with drum brakes.
Rear axle SINOTRUK MCX16ZG Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:5.29;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.
Wheels &Tire Rims:8.5-20 10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire.
Electrical system Electrics Operating voltage 24V,negative grounded
Starter 24V,7.5 Kw
Alternator 3-phase,28V,1500 W
Batteries 2x12 V,165 Ah
Horn,headlamps,fog lights,brake lights,indicators and reverse light.
Oil Tank 300L fuel tank
Packing Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice

Manual Transmission Sinotruk HOWO 380 HP 6X4 Tipper / Dumper / Dump Truck 0
