Sinotruk HOWO 380 HP 6X4 Tipper / Dumper / Dump Truck

Hot sale Sinotruk HOWO 380 HP 6X4 Tipper/Dumper/Dump Truck for Prices

Product Description – HOWO-7 8×4 380HP Dump Truck

The HOWO-7 8×4 380HP dump truck is a high-performance, heavy-duty vehicle tailored for bulk material transport in construction, mining, and infrastructure projects. With an 8×4 drive system and a powerful 380-horsepower engine, it offers outstanding load capacity, durability, and adaptability to tough working conditions.

Key Features:

• Model: HOWO-7 8×4 Dump Truck

• Engine: WP10.380E22, Euro II emission, 380 horsepower

• Drive System: 8×4 (four axles, two front steering axles, two rear driving axles)

• Cab: HW76 new front face cab with single sleeper and air conditioning

• Gearbox: HW19710, 10-speed manual transmission with HW50 PTO

• Rear Axle: MCY16 double axle, final ratio 5.451

• Front Axle: VGD95 front axle

• Steering Gear: BOSCH technology for precise control

• Tires: 12.00R20 mixed pattern tires (12+1 spare), 18PR for high load capacity

• Fuel Tank: 300L fuel tank for long-distance hauling

• Dump Body: Reinforced box with optional sizes (e.g., 7500×2300×1500mm)

• Hydraulic System: Front lifting cylinder for fast and stable dumping

• Max Speed: Approximately 75–82 km/h

• Curb Weight: Approx. 16,000 kg

• Color: Standard optional colors available (e.g., red, white, green)

Advantages:

• Increased payload capacity with 8×4 axle configuration

• Reliable engine and transmission system for long service life

• Comfortable cab with good visibility and safety features

• Low maintenance cost, high fuel efficiency

• Strong chassis and dump body suitable for rough environments

  Model		ZZ3317N2867N1		ZZ3317N3067N1		ZZ3317N3267N1		ZZ3317N4067N1
  Engine	Euro2	336/371		336/371		336/371		336/371
  	(Euro3)	(340/380)		(340/380)		(340/380)		(340/380)
  Cab		A7-W Lengthen cab		A7-W Lengthen cab		A7-W Lengthen cab		A7-W Lengthen cab
  Transmission		HW15710		HW15710		HW15710		HW15710
  		HW19710		HW19710		HW19710		HW19710
  Front axle		HF9 Disc		HF9 Disc		HF9 Disc		HF9 Disc
  Rear axle		AC16		AC16		AC16		AC16
  Steering		ZF8098		ZF8098		ZF8098		ZF8098
  Tyres		12.00R20		12.00R20		12.00R20		12.00R20
  Dump box dimensions(mm)		6200x2300x1500		6500x2300x1500		6800x2300x1500		7600x2300x1500
  Cubage (m3)		21.39		22.42		23.46		26.22
  Steel thickness(mm)		Floor:8/Side:6		Floor:8/Side:6		Floor:8/Side:6		Floor:8/Side:6
  Hydraulic Lift		Front Lift		Front Lift		Front Lift		Front Lift

  Cabin	Driving type 8x4 LHD/RHD
  	A7-B Low-floor standard cab,no bunk,safety belts, MP5,air conditioner,Central door lock, electric window lifter,Electric mirrors(with heating)
  Wheel Base	4600+1350+1350 mm
  GVW	31000kg
  Front axle loading capacity	2 x 9000
  Rear axles loading capacity	2 x 16000
  Engine	Brand	Sinotruk
  	Model	WD12.42
  	Type	6-cylinder in line,4-stroke,water-cooled,supercharging  intermediate cooler,high pressure common rail
  	Displacement	11.596L
  	Bore x Stroke	126x155mm
  	Horse Power (HP)	420
  	Emission standard	Euro III
  Max Speed	75 km/h
  Tire	12.00-20, 12.00R20
  Carriage	The carriage can be heightening Steel thickness of Carriage floor optional 8,10,12,14,16mm Steel thickness of Carriage side optional 4,6,8,10,12,14mm Ordinary steel,optional Manganese plate-Mn16,high strength steel
  Carriage lifting mode	4800-5600mm middle lift F type and strengthening T type. 5600-5800mm front lift CHINA system and HYVA system
  Transmission	HW15710 or HW19710 transmission,10 forward and 2 reverse
  Steering	ZF8098
  Oil Tank	300L
  Brake System	Service brake:dual circuit compressed air brake
  	Parking brake (emergency brake):spring energy,compressed air operating on rear wheels
  	Auxiliary brake:engine exhaust valve brake
  Electrics	Operating voltage:24V,negative grounded
  	Batteries:2x12 V,165 Ah
  	horn,headlamps,fog lights,brake lights,indicators and reverse light
  Option	ABS;Automatic Break Clearance Adjusting Arm;Traveling Data Recorder;Metal Pipeline; Engine Protective Board;Guard grating for engine oil bottom case;all-metal front protection frame
