Sinotruk HOWO 380 HP 8×4 Dump Truck with 50t Load Capacity for Heavy Duty Material Transport

Sinotruk HOWO 380 HP 8×4 Dump Truck with 50t Load Capacity for Heavy Duty Material Transport

  • Sinotruk HOWO 380 HP 8×4 Dump Truck with 50t Load Capacity for Heavy Duty Material Transport
  • Sinotruk HOWO 380 HP 8×4 Dump Truck with 50t Load Capacity for Heavy Duty Material Transport
  • Sinotruk HOWO 380 HP 8×4 Dump Truck with 50t Load Capacity for Heavy Duty Material Transport
  • Sinotruk HOWO 380 HP 8×4 Dump Truck with 50t Load Capacity for Heavy Duty Material Transport
Sinotruk HOWO 380 HP 8×4 Dump Truck with 50t Load Capacity for Heavy Duty Material Transport
Product Details:
Place of Origin: China
Brand Name: howo
Certification: iso,ce
Model Number: howo-7
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: NEGOTIABLE
Packaging Details: nude
Delivery Time: 40 worker days
Payment Terms: L/C,T/T
Supply Ability: 500 units/month
Contact Now
Detailed Product Description
Model NO.: Howo8*4 Dump Truck Transmission Type: Manual
Load Capacity: 50t Drive Wheel: 8×4
Horsepower: 371hp Tire Certification: ECE, GCC, ISO, DOT
Condition: New Drive Seat: Air Suspension Seat
Highlight:

Sinotruk HOWO Tipper

,

380 HP Tipper

,

6X4 Tipper

Sinotruk HOWO 380 HP 6X4 Tipper / Dumper / Dump Truck
Hot sale Sinotruk HOWO 380 HP 6X4 Tipper/Dumper/Dump Truck
Product Description - HOWO-7 8×4 380HP Dump Truck
The HOWO-7 8×4 380HP dump truck is a high-performance, heavy-duty vehicle engineered for bulk material transport in construction, mining, and infrastructure projects. Featuring an 8×4 drive system and a robust 380-horsepower engine, it delivers exceptional load capacity, durability, and adaptability to demanding working environments.
Key Features
  • Model: HOWO-7 8×4 Dump Truck
  • Engine: WP10.380E22, Euro II emission, 380 horsepower
  • Drive System: 8×4 (four axles, two front steering axles, two rear driving axles)
  • Cab: HW76 new front face cab with single sleeper and air conditioning
  • Gearbox: HW19710, 10-speed manual transmission with HW50 PTO
  • Rear Axle: MCY16 double axle, final ratio 5.451
  • Front Axle: VGD95 front axle
  • Tires: 12.00R20 mixed pattern tires (12+1 spare), 18PR for high load capacity
  • Fuel Tank: 300L fuel tank for long-distance hauling
  • Dump Body: Reinforced box with optional sizes (e.g., 7500×2300×1500mm)
  • Hydraulic System: Front lifting cylinder for fast and stable dumping
  • Max Speed: Approximately 75-82 km/h
  • Curb Weight: Approx. 16,000 kg
  • Color: Standard optional colors available (e.g., red, white, green)
Advantages
  • Increased payload capacity with 8×4 axle configuration
  • Reliable engine and transmission system for long service life
  • Comfortable cab with excellent visibility and safety features
  • Low maintenance cost with high fuel efficiency
  • Robust chassis and dump body designed for rough environments
Model Specifications Comparison
Model ZZ3317N2867N1 ZZ3317N3067N1 ZZ3317N3267N1 ZZ3317N4067N1
Engine Euro2 336/371
(Euro3 340/380)		 Euro2 336/371
(Euro3 340/380)		 Euro2 336/371
(Euro3 340/380)		 Euro2 336/371
(Euro3 340/380)
Cab A7-W Lengthen cab A7-W Lengthen cab A7-W Lengthen cab A7-W Lengthen cab
Transmission HW15710
HW19710		 HW15710
HW19710		 HW15710
HW19710		 HW15710
HW19710
Front Axle HF9 Disc HF9 Disc HF9 Disc HF9 Disc
Rear Axle AC16 AC16 AC16 AC16
Steering ZF8098 ZF8098 ZF8098 ZF8098
Tyres 12.00R20 12.00R20 12.00R20 12.00R20
Dump Box Dimensions (mm) 6200×2300×1500 6500×2300×1500 6800×2300×1500 7600×2300×1500
Cubage (m³) 21.39 22.42 23.46 26.22
Steel Thickness (mm) Floor:8/Side:6 Floor:8/Side:6 Floor:8/Side:6 Floor:8/Side:6
Hydraulic Lift Front Lift Front Lift Front Lift Front Lift
Technical Specifications
Cabin Configuration
Driving type 8x4 LHD/RHD
A7-B Low-floor standard cab, no bunk, safety belts, MP5, air conditioner, Central door lock, electric window lifter, Electric mirrors (with heating)
Chassis Specifications
  • Wheel Base: 4600+1350+1350 mm
  • GVW: 31000kg
  • Front Axle Loading Capacity: 2 x 9000
  • Rear Axles Loading Capacity: 2 x 16000
Engine Details
  • Brand: Sinotruk
  • Model: WD12.42
  • Type: 6-cylinder in line, 4-stroke, water-cooled, supercharging intermediate cooler, high pressure common rail
  • Displacement: 11.596L
  • Bore x Stroke: 126x155mm
  • Horse Power (HP): 420
  • Emission Standard: Euro III
  • Max Speed: 75 km/h
Additional Components
  • Tire: 12.00-20, 12.00R20
  • Transmission: HW15710 or HW19710 transmission, 10 forward and 2 reverse
  • Steering: ZF8098
  • Oil Tank: 300L
Brake System
  • Service Brake: dual circuit compressed air brake
  • Parking Brake (Emergency Brake): spring energy, compressed air operating on rear wheels
  • Auxiliary Brake: engine exhaust valve brake
Electrical System
  • Operating Voltage: 24V, negative grounded
  • Batteries: 2x12 V, 165 Ah
  • Standard Features: horn, headlamps, fog lights, brake lights, indicators and reverse light
Carriage Options
  • The carriage can be heightening
  • Steel Thickness of Carriage Floor: optional 8,10,12,14,16mm
  • Steel Thickness of Carriage Side: optional 4,6,8,10,12,14mm
  • Material Options: Ordinary steel, optional Manganese plate-Mn16, high strength steel
Carriage Lifting Modes
  • 4800-5600mm middle lift F type and strengthening T type
  • 5600-5800mm front lift CHINA system and HYVA system
Optional Features
  • ABS
  • Automatic Break Clearance Adjusting Arm
  • Traveling Data Recorder
  • Metal Pipeline
  • Engine Protective Board
  • Guard grating for engine oil bottom case
  • All-metal front protection frame
Sinotruk HOWO 380 HP 8×4 Dump Truck with 50t Load Capacity for Heavy Duty Material Transport 0
