Name: Sinotruk HOWO Camion Volteo Manufacturer 6X4 8X4 340HP 380HP 400HP Truck
Brand: Shandong Global Heavy Truck Import&Export Co.,Ltd
SKU: howo
Price: 37,000.00 USD
Availability: InStock

Home Products Heavy Duty Dump Truck

Sinotruk HOWO Camion Volteo Manufacturer 6X4 8X4 340HP 380HP 400HP Truck

Product Details:

Place of Origin:	China
Brand Name:	sinotruk
Certification:	iso,
Model Number:	howo

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	NEGOTIABLE
Packaging Details:	nude
Delivery Time:	40 worker days
Payment Terms:	L/C,T/T
Supply Ability:	500 units/month

Contact Now

Detailed Product Description

Model NO.:	Howo 6*4 Dump Truck	Transmission Type:	Manual
Load Capacity:	31-40t	Drive Wheel:	6×4
Traction Type:	6*4, Left/Right Hand Drive8	Gear Box:	9 Forward Gears& 1 Reverse
Condition:	New	Drive Seat:	Air Suspension Seat
Highlight:	340HP Sinotruk HOWO Camion Volteo , 8X4 Sinotruk HOWO Camion Volteo , 380HP Sinotruk HOWO Camion Volteo

Hot-Sale Good Price Sinotruk HOWO Camion Volteo Manufacturer 6X4 8X4 340HP 380HP 400HP Truck


			SINOTRUK HOWO Dump Truck

			Chassis Model
			ZZ3257N3847B1 (Left/ Right Hand Driving Type Optional)

			Driving type
			4X2 6x4 8X4 4X4 6X6 8X8

			Engine
			Model: WD615.47, Euro 2, 371 HP

			6-cylinder in-line with water cooling, turbo-charging and intercooling

			Displacement: 9.726 L

			371HP / 340HP / 340HP / 380HP / 400HP / 430HP, Euro II / V

			Clutch
			Single-plate dry diaphragm spring clutch,diameter430mm,hydraulically operating with air assistance

			Gearbox
			SINOTRUK BRAND, manual operation, HW19710, 10 forward and 2 reverse, with Power Take-Off (PTO)

			Front Axles
			VGD95 9500kg with drum brake system

			Rear Axles
			HC16, 2X16000kg, double stage reduction (central+ hub), cast axle housing, ratio: 5.73

			Suspension
			Front suspension: 10 pcs leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer

			Rear suspension: 12 pcs leaf springs with bogie spring and stabilizer

			Steering System
			famous brand power steering, model ZF8118 , hydraulic steering with power assistance

			Braking System

			Front drum rear drum brake, four-circuit protection valve

			Service brake: dual circuit compressed air brake

			Parking Brake(emergency brake): spring energy, compressed air operating on rear wheels

			Auxiliary brake (optional): engine exhaust brake(EVB), antilock brake system (ABS), automatic brake gap adjustment arms

			Tires
			12.00R20 (12.00-20, 315/80R22.5 optional), with one spare tyre

			Fuel Tank Volume (L)
			300

			Dead Weight
			12020/8630

			Gross Vehicle Weight (kg)
			25000

			Rated Loading Weight (kg)
			12850; 12640 optional

			Overall Dimension

			(LxWxH) (mm)
			8650x2550x3500

			Wheelbase (mm)
			3800+1350

			Min.Ground Clearance (mm)
			314

			Approach/Depart Angle(°)
			19/ (27/65)

			Gradeability (%)
			≥50

			Min. Turning Diameter (m)
			15

			Cargo Body Size (LxWxH) (mm)
			5600x2300x1500 option

			Cargo Body Volume (m3)
			19 option

Tag:

construction dump truck,

heavy duty tipper trucks,

sand dump truck

Contact Details

Shandong Global Heavy Truck Import&Export Co.,Ltd

Contact Person: Mr. Zhang

Tel: 86-15275410816

Other Products

ZZ3257N3647A Heavy Duty Dump Truck With Ferman ZF Steering And 18 CBM Capacity

Model:: ZZ3257N3647A

Cabin:: HW76

Rear axle:: HC16

Front Axle:: HF9

Sinotruk Howo 371HP 6X4 10 Tire Tipper Truck Euro 2 300L Fuel Tank

Drive Wheel: 6x4

Horsepower: 351 - 450hp

Front axle: HF9

Tyre: 12.00R20, radial tyres with one spare tyre

ZZ3257N3647N1 Ten Wheel Heavy Duty Dump Truck With A7-W Cabin And ZF Steering

Model: ZZ3257N3647N1

Fuel: Diesel

Cab: A7-W

Color: Optional

FAW Jiefang J5P Big Tractor Trucks , Manual 6*4 Heavy Duty Truck Tractor Head

Drive Wheel: 6x4

Capacity (Load): 21 - 30t

Horsepower: 251 - 350hp

Condition: New

266-345hp Howo 6x4 Dump Truck 30 T Diesel Fuel Type Stable Structure

Drive Wheel: 6x4

Horsepower: 251 - 350hp

Transmission Type: Manual

Fuel Type: Diesel

Durable Sinotruk Howo 6x4 Dump Truck 371hp With Overturning Body Platform Euro 2

Drive Wheel: 6x4

Horsepower: 251 - 350hp

Transmission Type: Manual

Fuel Type: Diesel

Howo A7 8x4 28.29CBM Heavy Duty Dump Truck With HW19710 Transmission

Drive Wheel: 8x4

Gross Vehicle Weight: 31000

Engine: WD615.47

Color: Optional

SINOTRUK HOWO Dump Truck
Chassis Model	ZZ3257N3847B1 (Left/ Right Hand Driving Type Optional)
Driving type	4X2 6x4 8X4 4X4 6X6 8X8
Engine	Model: WD615.47, Euro 2, 371 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L 371HP / 340HP / 340HP / 380HP / 400HP / 430HP, Euro II / V
Clutch	Single-plate dry diaphragm spring clutch,diameter430mm,hydraulically operating with air assistance
Gearbox	SINOTRUK BRAND, manual operation, HW19710, 10 forward and 2 reverse, with Power Take-Off (PTO)
Front Axles	VGD95 9500kg with drum brake system
Rear Axles	HC16, 2X16000kg, double stage reduction (central+ hub), cast axle housing, ratio: 5.73
Suspension	Front suspension: 10 pcs leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer
Suspension	Rear suspension: 12 pcs leaf springs with bogie spring and stabilizer
Steering System	famous brand power steering, model ZF8118 , hydraulic steering with power assistance
Braking System	Front drum rear drum brake, four-circuit protection valve Service brake: dual circuit compressed air brake Parking Brake(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake (optional): engine exhaust brake(EVB), antilock brake system (ABS), automatic brake gap adjustment arms
Tires	12.00R20 (12.00-20, 315/80R22.5 optional), with one spare tyre
Fuel Tank Volume (L)	300
Dead Weight	12020/8630
Gross Vehicle Weight (kg)	25000
Rated Loading Weight (kg)	12850; 12640 optional
Overall Dimension (LxWxH) (mm)	8650x2550x3500
Wheelbase (mm)	3800+1350
Min.Ground Clearance (mm)	314
Approach/Depart Angle(°)	19/ (27/65)
Gradeability (%)	≥50
Min. Turning Diameter (m)	15
Cargo Body Size (LxWxH) (mm)	5600x2300x1500 option
Cargo Body Volume (m3)	19 option
