12 Wheels Howo 8x4 Dump Truck , Construction Dump Truck Euro 2 Emission Standard

12 Wheels Howo 8x4 Dump Truck , Construction Dump Truck Euro 2 Emission Standard

    • 12 Wheels Howo 8x4 Dump Truck , Construction Dump Truck Euro 2 Emission Standard
    • 12 Wheels Howo 8x4 Dump Truck , Construction Dump Truck Euro 2 Emission Standard
    • 12 Wheels Howo 8x4 Dump Truck , Construction Dump Truck Euro 2 Emission Standard
    • 12 Wheels Howo 8x4 Dump Truck , Construction Dump Truck Euro 2 Emission Standard
  • 12 Wheels Howo 8x4 Dump Truck , Construction Dump Truck Euro 2 Emission Standard

    Product Details:

    Place of Origin: JINAN CITY OF SHANDONG
    Brand Name: SINOTRUK HOWO
    Certification: ISO/CCC
    Model Number: ZZ3317N4267A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 UNIT
    Price: Negotiable
    Packaging Details: Package in Nude
    Delivery Time: 30-45 work days
    Payment Terms: L/C, T/T
    Supply Ability: 5000 UNITS/Mouth
    Contact Now
    Detailed Product Description
    Gross Vehicle Weight (Kg): 31000 Transmission: HW19710 Transmission ,10 Forward And 2 Revers
    Maximum Driving Speed (km/h): 80 Wheel Base: 1800+4600+1350mm
    Emission Standard: Euro 2 Fuel Consumption (1/100 Km): 44.1
    High Light:

    sand dump truck

    ,

    construction dump truck

    ZZ3317N4267A Yellow color 336 HP 8x4 Dump Truck 12 wheels with HW19710 transnission



    Description:



    HOWO 8x4 Dump Truck is produced by SINOTRUK.It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials, which is the best choice for heavy construction vehicle customers.And exported more than eighty countries and regions,for example Ethiopia,Kenya,South Africa,The Philippines,Saudi Arabia,Malaysia,Nigeria,Peru,Russia...We can give customer most suitable advice when customer has special needs for your transportation or construction,the output torque automatically according to loads change.which is the best choice for heavy construction vehicle customers.



    Our advantages:



    1. Warranty: one year or 10000 km

    2. Production time: within 35 working days

    3. After-sale service team:highly trained with overseas working experience

    4. Support service:response quickly in 12 hours and provide professional technical

    5. Shipping:professional transport team,safety and quickly



    SINOTRUK HOWO 8x4 Dump Truck Specifications



    Body

    Carriage Internal Dimensions(mm) 7800x2300x1500
    Cubage (m3) 26.91
    Steel thickness of Carriage(mm) Floor:8mm/Side:6mm
    Steel Q235
    Hydraulic Lift of Carriage Middle Lift



    Weight in kg

    Kerb weight (Kg) 10400
    Gross vehicle weight (Kg) 31000



    Dimension(mm)





    Dimensions(mm)

    Length(mm) 9850
    Width(mm) 2496
    Height(mm) 3125
    Wheel base (mm) 1800+4200+1350
    Angle( ̊ ) Approach 14
    Departure 47



    Performance

    Maximum driving speed (km/h) 80
    Fuel consumption (1/100 km) 44.1



    Cab

    Model SINOTRUK HW76 Low-floor Lengthen cab
      HW76 cab, (single sleeping, with air-condition), all-steel forward control,70̊ hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds,laminated windscreen with casted-in radio aerial,hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat,with heating and ventilating system,outer sun visor,adjustable roof flap,with stereo radio/cassette recorder,safety belts and adjustable steering wheel,air horn,with 4-point support fully floating suspension and shock absorbers.



    Engine

    Model WD615.69(Euro 2)
    Type 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection
    Horsepower 336
    Bore x Stroke 126x130mm
    Valve 2
    Displacement 9.726L
    Transmission SINOTRUK HW19710 transmission ,10 forward and 2 reverse



    Clutch

    SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance



    Steering

    ZF8118 Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving)

    Front Axle

    SINOTRUK HF9 Front Axle
    Suspension Front overhang 1500mm
    Rear overhang 1000mm



    Rear Axles

    SINOTRUK AC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:5.45



    Brake System

    Service brake:dual circuit compressed air brake

    Parking brake (emergency brake):spring energy,compressed air operating on rear wheels

    Wheels & Tyres Rims 10 hole-steel
    Tyres 12.00R20 radial tyre with 1 Spare tire.
    Wheel tread 2022/2022,2041/2041,1830/1830mm



    Electrics

    Operating voltage:24V,negative grounded

    24V,7.5KW.Starter:24V,7.5 Kw

    28V,1500W.Alternator:3-phase,28V,1500 W

    2x12V,165Ah.Batteries:2x12 V,165 Ah

    horn,headlamps,fog lights,brake lights,indicators and reverse light

    Oil Tank 400L Aluminum alloy fuel tank



    12 Wheels Howo 8x4 Dump Truck , Construction Dump Truck Euro 2 Emission Standard 012 Wheels Howo 8x4 Dump Truck , Construction Dump Truck Euro 2 Emission Standard 1
