Hazardous Chemical Transporter Truck With HW76 Cabin ZZ1317N4667W 8X4 Euro 2

Hazardous Chemical Transporter Truck With HW76 Cabin ZZ1317N4667W 8X4 Euro 2

    • Hazardous Chemical Transporter Truck With HW76 Cabin ZZ1317N4667W 8X4 Euro 2
    • Hazardous Chemical Transporter Truck With HW76 Cabin ZZ1317N4667W 8X4 Euro 2
    • Hazardous Chemical Transporter Truck With HW76 Cabin ZZ1317N4667W 8X4 Euro 2
    • Hazardous Chemical Transporter Truck With HW76 Cabin ZZ1317N4667W 8X4 Euro 2
  • Hazardous Chemical Transporter Truck With HW76 Cabin ZZ1317N4667W 8X4 Euro 2

    Product Details:

    Place of Origin: JINAN CITY OF CHINA
    Brand Name: HOWO
    Certification: ISO9001
    Model Number: ZZ1317N4667W

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 UNIT
    Price: Negotiable
    Packaging Details: Nude
    Delivery Time: 30-45 work days
    Payment Terms: L/C, T/T
    Supply Ability: 500 units/month
    Contact Now
    Detailed Product Description
    Model: ZZ1317N4667W Engine: WD615.69
    Steering: ZF8118 Overall Dimensions: 11700X2496X3025mm
    Cabin: HW76 Displacement: 9726ml

               ZZ1317N4667W SINOTRUK 8X4 Euro 2 Hazardous Chemical Transporter Truck With HW76 Cabin



    Description:


    HOWO 8x4 cooking oil tanker truck now is good products in overseas market, the frame adopt U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members

    Front suspension adopt 10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer.Rear suspension adopt 12 leaf semi-elliptic springs, bogie spring and stabilizer.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.Professional Sales Team of trucks. Our target is not selling trucks; we help customers choose the best suitable trucks as per customer’s situation.



    Packing:



    Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.The main machine nude, attached parts and tools put into standard export box.Within 20 days deliver the goods to main Port.Ro-Ro ship or bulk ship or according to customer requiring.
    We have professional forwarding partners.


    Competitive Advantage:



    1. Flexible and convenient logistic service.
    2. Excellent and high-quality control

    3. Rich experience and well after-sale service.

    4. Long lasting working life time.

    5. Rich experience and well after-sale service.

    6. Long lasting working life time.
    7. Shippping: we have logistic team, can cargo your truck fast and safety.



    Chassis model ZZ1317N4667W
    Overall dimensions 11700X2496X3025mm
    Front/rear wheel track 2022/2041, 1830/1830mm
    Approach/departure angle 16/19°
    Tank thickness 6mm
    Cab HW76 a row and a half deluxe cab(with sleeping berth), allowable 3 passengers
    Engine WD615.69
      Euro 2
    Type 6 cylinders, in-line, 4-stroke, water cooled, turbo inter-cooling, direct injection, diesel engine
    Rated power 336hp, rated power speed 2200rpm
    Displacement 9726ml
    Max.torque 1350N.m
    Bore x stroke 126x130mm
    Tire

    12.00R20 tubeless tire

    12+1 nos

    Clutch φ430 diaphragm clutch
    Fuel tank 400L oil tank
    Front axle HF 7 tons
    Rear axle HC 16 tons
    Drive form 8X4
    Rated voltage 24V, DC
    Transmissions  HW15710 , 10 speed forward 2 reverse.
    Steering device Power assisted steering
    Steering wheel Left hand drive
    Tank dimensions 9800×2500×1900mm
    Tank volume 40000L
    Tank thickness 6mm
