Durable 3-Axle Lowbed Semi Trailer – Designed for Heavy Haulage in Ghana

Overview
This 3-axle lowbed semi trailer is purpose-built to serve Ghana’s growing demand for transporting heavy construction and mining machinery. Whether you are moving excavators, wheel loaders, drilling rigs, or paving equipment, this trailer delivers the strength, ground clearance, and structural reliability needed for Ghana’s roads and project sites.

Key Specifications
Total length: 13,000 mm
Platform width: 3,000 mm
Platform height: 850–1000 mm
Loading capacity: 40 to 80 tons depending on configuration
Main beam: Welded Q345B H-beam steel, reinforced chassis
Axles: 3 units, 13T FUWA or BPW type
Tires: 12 pieces, 12R22.5 or 315/80R22.5
Suspension: Heavy-duty mechanical leaf spring or optional air suspension
Brakes: Dual-circuit air brake with WABCO relay valve
Kingpin: 2” or 3.5” JOST brand, bolted
Landing gear: 28T two-speed manual operation
Ramps: Rear loading ramps – manual spring or hydraulic type
Surface finish: Sandblasted, coated with anti-rust primer and polyurethane paint
Extras: Toolboxes, spare tire holders, multiple lashing rings, widened extensions optional

Why It’s a Good Fit for Ghana

• Strong enough for long-distance hauls from Tema Port to northern construction zones

• Ideal for transporting Komatsu, CAT, SANY, and XCMG equipment

• Designed to handle rugged roads and uneven jobsite conditions

• Supports regional transport into Togo, Burkina Faso, and Côte d'Ivoire

• Low deck height for stable and safe loading of tall or oversized cargo

What Our Ghanaian Customers Say
“We operate a fleet of earthmoving machines and use this trailer regularly on national roads and mining routes. It performs well and is easy to maintain.”
— Joseph A., Mining contractor in Obuasi

“The loading angle is low enough for our dozers and graders. We requested hydraulic ramps, and the delivery matched our specs exactly.”
— Daniel B., Equipment logistics company, Takoradi

Common Questions and Answers

Q: Can the deck height or ramp type be customized?
Yes, we offer customization on loading height, ramp operation (manual or hydraulic), and platform width.

Q: How is this trailer shipped to Ghana?
We typically export via bulk vessel or flat rack container to Tema Port, depending on your order quantity.

Q: Are parts easy to replace locally?
Yes. We use standardized parts (tires, axles, brake systems) that are commonly available in West Africa.

Q: What documents are included with shipment?
We provide invoice, packing list, certificate of origin, and loading photos. SGS pre-shipment inspection can be arranged if required.

Q: Do you support after-sales service?
Certainly. We offer technical advice, remote support via WhatsApp, and fast spare parts supply when needed.

Delivery and Support
Shipping port: Qingdao / Tianjin / Lianyungang
Arrival port: Tema, Ghana
Documents provided: Full customs set including CO, invoice, packing list
Support: Loading photos, 24/7 WhatsApp support, spare parts assistance
