China Earthmoving Machinery 3ton Small Hydraulic Front Wheel Loader Xc938

China Earthmoving Machinery 3ton Small Hydraulic Front Wheel Loader Xc938

  • China Earthmoving Machinery 3ton Small Hydraulic Front Wheel Loader Xc938
  • China Earthmoving Machinery 3ton Small Hydraulic Front Wheel Loader Xc938
  • China Earthmoving Machinery 3ton Small Hydraulic Front Wheel Loader Xc938
  • China Earthmoving Machinery 3ton Small Hydraulic Front Wheel Loader Xc938
China Earthmoving Machinery 3ton Small Hydraulic Front Wheel Loader Xc938
Product Details:
Place of Origin: China
Brand Name: XCMG
Certification: iso/ccc
Model Number: Zl938
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiation
Packaging Details: Nude
Delivery Time: 30-45 work days
Payment Terms: L/C,T/T
Supply Ability: 400 Unit/Units per month
Contact Now
Detailed Product Description
Product Name: Loader Zl938 Certification: TUV, ISO, CE
Condition: New Rated Load: 1-3t
Transmission: Hydraulic Load And Unload Mode: Front Discharge
Walking Mode: Wheeled Specification: 7050× 2482× 3118mm
Highlight:

Small Hydraulic Front Wheel Loader

,

3ton Hydraulic Front Wheel Loader

,

China Hydraulic Front Wheel Loader

China Earthmoving Machinery 3ton Small Hydraulic Front Wheel Loader Xc938 for Sale

Product Description

XC938 wheel loader 3 ton front end loader with 1.8m3 bucket

New generation XC9 series intelligent medium-tonnage loader conformed to international stage-V emission regulation and features all-new streamline industrial exterior design, beautiful modeling, advanced and reliable performances, and high energy-conservation, efficiency, comfort, and convenience.

The high-torque electronic control engine matches excellently with 5-speed full-automatic transmission to realize high working efficiency.
The load-sensing hydraulic system remarkably improves the fuel economy.
The heavy-duty large-span front and rear articulated frame with tapered roller bearing articulated pivots guarantees the high firmness and durability.
The working device features intelligent control and high accuracy and efficiency and remarkably improves the comfort.
The international slightly pressurized low-noise panoramic cab conformed to the ergonomic requirements.
The full-tilting cab and the large-angle integrally backward-opening hood centralize the oil drainage and can realize the one-stop maintenances.  The optional diversified attachments, including sliding forks, clamp, lifting appliance, and quick change device, can be installed to realize multi-functionality.


1. It features high efficiency, energy-saving, and strong power.
2. The three-element torque converter and the fixed shaft power shift transmission feature high maturity and reliability.
3. The 2600mm wheelbase features high mobility and flexibility and is applicable to all kinds of working sites.
4. The bucket is made of high strength material to realize high wear and impact resistance.
5. The diversified configurations and complete attachments adapt to the construction needs in different regions and under
different working conditions.
6. The optional A/C and the sound insulation and noise reduction measure build elaborately a comfortable operating environment.



Description
Unit
Parameter value
Rated operating load
kg
3000
Bucket capacity
1.5~2.5
Machine weight
kg
10600±200
Dump clearance at maximum lift
mm
2770~3260
Reach at maximum lift
mm
1010~1210
Wheel base
mm
2600
Tread
mm
1850
Height of hinge at maximum lift height
mm
3830
Working height(fully lifted)
mm
4870
Max.breakout force
kN
130
Max.horse power
kN
95
Hydraulic cycle time-raise
s
5.5
Total hydraulic cycle time
s
10
Min. turning radius over tyres
mm
5165
Articulation angle
°
35±1
Gradeability
°
28
Tyre size

17.5-25-12PR
Overall machine dimension L×W×H
mm
7050×2482×3118
Model

WP6G125E22
Emission standards

Emission 2
Rated Power/Speed
kW/rpm
92/2200
Fuel Tank
L
170
Hydraulic Tank
L
170
