Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160

Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160

  • Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160
  • Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160
  • Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160
  • Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160
  • Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160
Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160
Product Details:
Place of Origin: China
Brand Name: XCMG
Certification: ISO/CE/CCC
Model Number: XMZ130 XMZ160
Payment & Shipping Terms:
Minimum Order Quantity: 1UNIT
Price: Negotiation
Packaging Details: Nude, but with wax sprayed.
Delivery Time: 35 working days after received payment
Payment Terms: LC/TT.
Supply Ability: 1,000 units per month
Contact Now
Detailed Product Description
Engine Model:: QSB6.7-C170 Engine Rated Power/speed:: 129/2200 KW/ R/min
Max. Torque:: 800/1400 N·m Weight Of Overall Unit: 13500kg
Dimension:: 8492×2291×3054mm
High Light:

pile driving equipment

,

borehole drilling machine

Bolt Drilling Machine XMZ130 XMZ160 concrete sleeper bolt drilling machine



Description:



XMZ130 Hydraulic Crawler Anchor Drilling Rig

XMZ130 Hydraulic Crawler Anchor Drilling Rig is specially designed for Micro-piles work. The characteristic of this rig is excellent motility reliability and high productivity. The active and passive safety device can ensure the maximum security and provide a full range of protection. This machine can work in different types according to the needs. So this kind of drill rig can be used to drilling construction micro-pipe and anchoring applications .



Features:



1. There are each two hydraulic outriggers in rear and front of the drill rig,with the outriggers it is easily to adjust the degree of level of the machine and can effectively guarantee the rig body stability and the accuracy of hole.

2. The complex connecting rod derricking system with multiple degrees of freedom provides transport convenience, and make it possible that even working in a narrow and small work region.

3. It adopts the Cummins electric control turbo-supercharged engine to provide strong power and conformity with Euro III emission standard.

4. It adopts the Euro Drill HD5012 rotary head, the max. torque can be 14100Nm,high speed and low speed modes provide a high applicability of the machine in different layer.

5. The speed of pulling and feeding of the rotary head can be changed inhigh mode and slow mode, makes it more efficiency that when drilling and hoisting in slow mode and when loading and discharging in fast mode, makes it more efficiency.

6. The normal size of the rod can be passed through the clamps is 50~255mm,the maximum breaking torque of the clamp is 30kNm and maximum clamping force is 150kN, this configuration can easily satisfied the demand of normal project.



Specifications:



Description Unit Data
Engine Model   QSB6.7-C170
Rated power/speed kW 129/2200r/min
Max. Torque N·m 800/1400
Fuel tank capacity L 340
Rotary head Model   Euro Drill HD5012
low operation Max. torque N·m 14100
Rotary speed r/min 39
Fast operation Max. Torque N·m 7050
Rotary speed r/min 78
Vibration power N·m 650
Vibration frequency min-1 2300
Hydraulic system Main pump Max. pull-down piston push Mpa 25
Main pump L/min 176+129
Auxiliary pump L/min 43
Hydraulic oil tank capacity L 450
Hoist & Feed
system
Feed type   Jack
Feed stroke mm 4714
Maximum hoist pull kN 100
Maximum feed force kN 50
Maximum hoist pull speed m/min 12.4
Maximum feed speed m/min 25.6
Winch Line pull(1st layer) kN 20
Maximum rope speed m/min 30
Rope diameter mm 12
Rope capacity m 50
Undercarriage Travelling speed km/h 3.5
Max. climbable gradient of the overall unit % 36
Track shoe width mm 400
Over all width mm 2250
Overall length mm 3040
Average ground pressure kPa 73
Clamps Nominal size mm 50-255
Maximum Clamping force kN 150
Maximum breaking torque kN·m 30
Dimension in transport condition (L × W × H) mm 8492×2291×3054
Weight of overall unit(standard configuration) kg 13500

Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160 0Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160 1Hydraulic Crawler Excavator Concrete Sleeper Bolt Drilling Machine XCMG XMZ130 XMZ160 2
