BZCY600CWY Truck Mounted Drilling Rig 8×4 Chassis Of Brand SINOTRUK

BZCY600CWY Truck Mounted Drilling Rig 8×4 Chassis Of Brand SINOTRUK

  • BZCY600CWY Truck Mounted Drilling Rig 8×4 Chassis Of Brand SINOTRUK
  • BZCY600CWY Truck Mounted Drilling Rig 8×4 Chassis Of Brand SINOTRUK
BZCY600CWY Truck Mounted Drilling Rig 8×4 Chassis Of Brand SINOTRUK
Product Details:
Place of Origin: China
Brand Name: BINZUAN
Certification: ISO/CCC
Model Number: BZCY600CWY
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: Negotiable
Packaging Details: Nude
Delivery Time: 30-45 work days
Payment Terms: L/C, T/T
Supply Ability: 500 units/month
Contact Now
Detailed Product Description
Model: BZCY600CWY Bearing Capacity (t): 36
Drilling Depth(M): 600 Engine: D10-27-40 Diesel Engine
D10-27-40 Diesel Engine: 500 Transport Size(L*W*H)(mm): 12725×2490×4208
Working Size(L*W*H)(mm): 11825×5374×14008 Drilling Power(KW): 132
High Light:

pile driving equipment

,

borehole drilling machine

 High Quality BZCY600CWY Truck Mounted Drilling Rig 8×4 Chassis Of Brand SINOTRUK



Product Specifications:



Technical parameter
Drilling depth(M) 600
Drilling diameter(mm) 500
Speed of turntable(r/min) 110;96;56;36;21;12(reverse)
Torque of turntable(KN.m) 4.3,5,8.5,13.,22.7,40(reverse)
The capacity of oil pump (KN/mpa) 245/20
The feeding force of oil pump (KN/mpa) 59/10
The single rope capacity of main windlass(KN) 50
The lifting capacity of main hook(KN) 300
The single rope capacity of tool windlass(KN) 20
The single rope capacity of tool hook(KN) 20
The height of mast (mm) 11800
Bearing capacity (t) 36
Pipe Kelly (mm) 108×108×7500
Assistant pipe (mm) Ф89×10×5500

BW850/2A

mud pump

Theory of flow (L / min) 600 850
Rated pressure (Mpa) 3 2
Pounding times (min-1) 58 82
Diameter of suction tube (mm) 127
Diameter of drain pipe (mm) 64
Input speed (r / min) 470
Input power (kw) 40
Overall dimensions (mm) 2000*1030*1400
Weight (t) 1.5





Drilling Power

diesel engine COMMINS 6BTA5.9-C180
Power(KW) 132
Speed (r/min) 2200
Out-put Torque(KN.m) 750Nm/1300 rpm
Truck chassis Model SINOTRUK
Drive form 8×4
Engine Model D10-27-40 diesel engine
Rated power(KW) 196
Speed (r/min) 2200

Electric generator Model MF
Rated power (kw) 30
Rated voltage(v) 400
Rated current(A) 27
Speed (r/min) 1500
Frequency(Hz) 50
Protection level IP21
Insulation Class H
Transport size(L*W*H)(mm) 12725×2490×4208
Working size(L*W*H)(mm) 11825×5374×14008





Main features:



◎BZCY600CWY truck mounted drilling rig is a directly rotary drilling rig. This truck chassis is adopt the 8×4 special chassis of brand SINOTRUK, 11.00R20 steel off-road tire tread, with good off-road performance.

◎This rig has very compact structure, the engine of chassis is adopted D10.27-40 diesel engine, the power is 196kw(strong power) The drilling rig has independent diesel engine (COMMINS 6BTA5.9-C180), the power is 132kw. Not only meet the drilling requirements, but also reduce energy consumption, it is very affordable.

◎This rig is design principle is an advanced hydraulic cylinder for drilling, stepless lift, it can be achieved automaic drilling. it can automatically adjust the drilling speed for different geological conditions.

◎The drilling process can be achieved in pressruized drilling technology, adjust different pressure for different geological conditions, and can be viewed drilling pressure by pressure gauge. At the same time, it can adjust the drilling speed.

◎The drilling rig can achieved fast drilling by manually, especially for soil. It can achieved different speed for different soil.

◎It has a large lifting force hydraulic main hoist, stepless lift, and to achieve release rope quickly. When upgrading heavy, the lifting speed need slow to aviod crash the turntable and wellhead board. When put down single drill pipe, operate the quick handle, it can achieved release rope quickly like mechanical hoist.

◎It has a hydraulic tool hoist, the tool hoist has large lifting force and quick lifting speed, it is both easy to loading drill tools, drill pipe and drill accessories transport, and can slide up and down with anchors, its very convenient to load and unload the drill pipe.

◎It has a hydraulic cylinder control double card board forward and backward, it makes the insurance card board closed, to achieve stuck or release the pipe joints.

◎It use integrated design of pneumatic, to achieve the 3NB-130 mud pump clutch using pneumatic remote control, it has high degree of automation and easy-saving operation.

◎It is installed 4 hydraulic legs and 2 mechanical legs, every hydraulic leg rod with locknut. After leveling the rig, it can lock the cylinder use locknut. So, even if the cylinder leaks, the chassis is not instability.

◎The turntable use stir bars, internal turntable use spiral arc gear to transmission, it has large torque, it about 2 times of similar products at domestic and foreign.

◎It is installed a generator (30kw) , so that it is convenient to illuminate or work at night.

◎The hydraulic system use open system, the chassis and drilling rig are separately manipulated, it can avoid misuse. Winter oil heater and summer oil radiator are installed, to adapt to different seasons hydraulic oil for heating and cooling.

◎This drilling rig equipped with an auxiliary unloading cylinder, it can be used to promote the turntable ratchet, to achieve auxiliary unloading the drill pipe.



Products pictures:



BZCY600CWY Truck Mounted Drilling Rig 8×4 Chassis Of Brand SINOTRUK 0BZCY600CWY Truck Mounted Drilling Rig 8×4 Chassis Of Brand SINOTRUK 1
