Sinotruk 10T Low Bed Semi Trailer Mechanical Suspension

Sinotruk 10T Low Bed Semi Trailer Mechanical Suspension

  • Sinotruk 10T Low Bed Semi Trailer Mechanical Suspension
  • Sinotruk 10T Low Bed Semi Trailer Mechanical Suspension
  • Sinotruk 10T Low Bed Semi Trailer Mechanical Suspension
Sinotruk 10T Low Bed Semi Trailer Mechanical Suspension
Product Details:
Place of Origin: CHINA
Brand Name: SINOTRUK
Certification: ISO/CCC
Model Number: LOW BED
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: Negotiable
Packaging Details: Nude
Delivery Time: 20 work days
Payment Terms: L/C, T/T
Supply Ability: 500 units/month
Contact Now
Detailed Product Description
Dimension(Lx W X H)(mm): 13000x3000x1700 Payload ( KG): 60000
Axle Number: FUWA,13ton.3axles Trailer Model: 3 Axle Low Bed Semi Trailer
Curb Weight(KG): 10000 Color: Optional
High Light:

Sinotruk Low Bed Semi Trailer

,

10T Low Bed Semi Trailer

,

Sinotruk heavy duty semi truck

10 Tons Curb Weight SINOTRUK 3 Axle 60 tons Low bed Semi Trailer with Mechanical suspension



Description:



SINOTRUK 3 Axle 60 tons Low bed Semi Trailer, can manufacture it according to your needs.And we  always use Q345B/6mm steel sheet.The Trailer suspensions can be: Air suspension, mechanic (leaf spring suspension), bogie suspension,.SINOTRUK Cargo trailer three axles low-bed trailer series side wall semi trailers ,fence semi trailer and van semi trailer are mainly used in heavy duty transportation for construction or logistic companies,such as bulk cargo transportin.Also the side wall of them are detachable.We have many years of experience in exporting trucks and trailers. We not only have the certificate and license of truck export but also strict quality management, fast and convenient channel of goods delivery, strict examination in quality and quantity of products.



Packing:



The whole trailer will be waxed before shipment; Shipped in Bulk Cargo, FR Container or by Roro.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.The main machine nude, attached parts and tools put into standard export box.Within 20 days deliver .


Competition advantages:


1. Specialization ,standard and accurate meet your requirement.
2. Product upgrading and expansion of species
3. Flexible and convenient logistic service.
4. Long lasting working life time.

5. We have been engaged in this industry for more than 20 years. High quality has always been our advantage.We have perfect transportation methods, which can greatly save your transportation cost.Our semi trailers can transport .



Product Description:



Trailer Model 3 Axle Low bed Semi Trailer
Dimension(Lx W x H)(mm) 13000x3000x1700
Curb Weight(KG) 10000
Payload ( KG) 60000
Departure Angle 16
Axle Number FUWA,13ton.3axles
Suspension system Mechanical suspension
Steel Spring 10/10/10
Frame

The height of the beam is500mm,

Top flange:20 mm

Middle flange:14mm

Bottom flange:20mm

Platform plate 5mm Diamond Plate
Tire Type and quantity 11.00R20 12units
Traction Pin 50mm or 90mm
Spare Wheel Bracket 2 pieces
Tool Box 1 Unit
Landing Leg 28T load landing leg
Brake system Dual Line braking system ,none ABS.
Brake air chamber 6 air chambers
Electrical system 24V,7 Pole plug


Tail lamp with turn signal, brake light & reflector,

side lamp etc.

  One set 6-core standard Cable.
Side Guard None
Painting Color by customer’s requirement
Packing Polish with wax before shipping
