Chassis 60 Ton 3 Axles 2 AXLES Lowboy Lowbed Low Bed Semi Trailers

Chassis 60 Ton 3 Axles 2 AXLES Lowboy Lowbed Low Bed Semi Trailers

Product Information

• Axles: 13T16P (Available brands: BPW, FUWA, Yonglitai, Huajin, etc.)
• Suspension: Mechanical / Air / Single-point suspension
• Color: Customizable
• Landing Gear: Standard 28-ton (Available brands: JOST, FUWA, etc.)
• Tires: 12R22.5 / 12R20
• King Pin: 2" (50mm) or 3.5" (90mm)

Packaging & Delivery

• Roll-on/Roll-off (RO-RO) shipping
• Container shipping (2-3 units per 40-foot container)
• Bulk cargo carrier (Stackable up to 3-4 units)

• 1-10 units: Approximately 30 days
• Over 10 units: To be negotiated

Product Features

1. High-Strength Material: Made with T700 high-strength steel, featuring thicker and wider main beams for enhanced durability, anti-twisting, and shock resistance.
2. Low Center of Gravity: Optimized design for stability when transporting ultra-tall loads and navigating overhead obstacles.
3. Adaptable to Various Roads: Suitable for long-distance transport on different road conditions.
4. Customization Available: Low bed semi-trailers with payloads ranging from 30 to 200 tons can be provided based on customer requirements.

Service Commitment

1. Customization: Offering tailored solutions for dimensions, configurations, and colors.
2. Quality Assurance: Strict adherence to international standards with rigorous quality inspections before delivery.
3. Lifelong Support: Providing long-term technical support and after-sales service.
4. Customer Satisfaction: No complaints from customers in the past 10 years, including large buyers, thanks to our quality and service.

Applications

• Heavy Machinery Transport: Excavators, loaders, road rollers, etc.
• Large Equipment Transport: Power generation units, storage tanks, mining equipment, etc.
• Special-Purpose Vehicles Transport: Buses, rail vehicles, forestry machinery, etc.

Trailer Model	2 3 4 Axles 40T 60T 80T 40FT 45FT Flat Bed Heavy Duty Semi Trailer
Size	12550 x2500 x 1600 mm
Curb Weight	6.4 ton (3Axle), 7.1 ton (4Axle),
Loading Capacity	40-80T
Container Lock	6-8 sets
Shipment	Load 1 20ft or 2 40ft Standard Shipping Containers or Bulk

Standard Configuration

Axle	13T
Axle number	2-4 Axles by Need
Traction pin	2 inch, Bolted Traction Pin
Fifth Wheel Type	50# or 90#
Suspension	Steel-plate spring
Tire Sizes	12R22.5 Tubeless Tire
Tire Number	8/12/16 pieces
Landing gear	28 tons, 2 Speed legs
Brake System	Handhold valve, Wabco Emergency Relay Valve
Electrical system	24V Electrical system With LED Light
Steel Ring	8.25-22.5 x 8/12
Spare tire carrier	1 Set with Spare-tire Lift System
Painting	Customizable
Packing	Nude Packing, Wax Before Shipment
