3 Axle 60 Ton Heavy Duty Lowbed Semi Trailer with Fuwa Axles

3 Axles 60tons Heavy Duty Lowbed Low Bed Lowboy Truck Semi Trailer for Sale

3-Axle Lowbed Semi Trailer – Strong, Stable, and Built for Nigeria’s Heavy Equipment Transport

Product Overview
Our 3-axle lowbed semi trailer is specially designed to transport heavy-duty equipment like excavators, bulldozers, transformers, and generators across Nigeria—from Lagos and Port Harcourt to Abuja and Kano. Built with high-tensile steel, reinforced loading ramps, and a low center of gravity, this trailer offers excellent stability on highways and rough terrain alike.

Technical Specifications

• Loading capacity: 50–70 tons (customizable)

• Overall length: 13,000 mm – 17,000 mm

• Width: 3,000 mm or per Nigerian regulation

• Platform height: 850 – 1,200 mm

• Axles: 3×13T FUWA or BPW, with ABS optional

• Suspension: Mechanical leaf spring or air suspension

• Tires: 12R22.5 or 315/80R22.5, 12 pcs

• Material: Q345 or T700 high-strength steel, welded H-beam

• Ramp: Spring-assisted or hydraulic folding type

• Kingpin: 2.0 or 3.5 inch JOST

• Landing gear: 28T two-speed

• Braking system: WABCO dual-line air brake

• Surface treatment: Full sandblasting + epoxy primer + top polyurethane paint

• Optional: Spare tire rack, toolbox, LED lights, container locks

Why It Works in Nigeria

• Suitable for moving construction and energy equipment across state borders

• Strong chassis designed to withstand overloads and bumpy roads

• Hydraulic or mechanical ramp options for easy loading

• Compatible with most 6x4 and 6x2 tractor heads in Nigeria

• Designed according to Nigerian axle load and width regulations

Client Feedback from Nigeria
"We use this trailer to transport bulldozers and CAT 320D excavators from Lagos to construction sites in the north. The loading ramp works smoothly and the trailer remains stable even at full capacity."
— Mr. Tunde A., equipment transport contractor

"The quality of steel and finishing is far better than our local trailers. The frame is solid, and the axles are reliable. We’ll be ordering more soon."
— Emeka O., heavy haulage fleet owner

Frequently Asked Questions (FAQ)

Q1: What equipment can this trailer carry?
It’s ideal for excavators, loaders, graders, large generators, containers, transformers, and other heavy machinery.

Q2: Can I choose between mechanical and hydraulic ramps?
Yes. Both are available. Most clients prefer hydraulic for ease of use, especially when loading 30-ton+ equipment.

Q3: Can the trailer be registered and operated in Nigeria without modification?
Yes. We build the trailer according to Nigerian transport regulations. If needed, we can provide documents for SONCAP or pre-shipment inspection.

Q4: Do you offer spare parts or after-sales service?
Yes. We provide extra brake pads, bushings, lamps, and support you via WhatsApp and email after delivery.

Q5: How is it shipped?
Normally by bulk vessel or flat rack to Lagos or Onne port. We support full loading inspection and provide all export documents.

Shipping & Support

• Loading ports: Qingdao, Lianyungang, or Tianjin

• Destination: Lagos / Onne / Port Harcourt

• Documents: Invoice, Packing List, Certificate of Origin, SONCAP (optional)

• Support: Remote assistance, spare parts supply, loading photos, full inspection video
